1.PRE-OPERATION INSTRUCTIONS

1.1 Unpacking and Product Confirmation

Take the option unit out of the package, check the unit name, and confirm that the product is as you
ordered and intact.
Functions arailable differ between FR-A500(L)/F500(L) series and FR-V500 series, always check before
using.
" SERIAL number check
This product may be used with the FR-A520-0.4K to 55K and FR-A540-0.4K to 22K manufactured in and
after November 1997. Any of the models may be used with this unit if its SERIAL number indicated on the
rating plate and package has the following version or later.
SERIAL is made up of 1 version symbol and 8 numeric characters indicating year, month, and control
number as shown below.
R 7
Symbol Year Month Control number
SERIAL number
Inverter
FREQROL-A series
500

1.2 Packing Confirmation

Make sure that the package includes the following
" Instruction manual.........................................................................1
" Mounting screws M3 × 10 .............................................................2
" Terminal resistor jumpers (Jumpers fitted to the terminal block)...1
$$$$$$
Y
Model
FR-A520-0.4, 0.75K, 11K to 22K
FR-A520-1.5 to 7.5K
FR-A520-30 to 55K
FR-A540-0.4 to 22K
SERIAL Number
$$$$$$
R7Y
$$$$$$
Q7Y
$$$$$$
G7Y
$$$$$$
G7Y
1
Date Manufactured
in and after
November 1997
