COMPUTER LINK FUNCTION
(4) Parameter setting write
For the parameters indicated in the "data code list" of the Inverter Instruction Manual, their settings can
be written.

4.5 Input from inverter to computer

(1) Inverter status
The following operating status can be monitored.
FREQROL-A500(L)/FR-F500(L) Series
bit
Terminal
symbol
0 RUN
1 —
2 —
3 SU
4 OL
5 IPF
6 FU
7 ABC
The terminal signals marked * are factory-setting. The output signals can be changed using output ter-
minal function selection (Pr. 190 to). Output terminal function selection differ in function between invert-
ers. For details, refer to the Inverter Instruction Manual.
(2) Inverter monitoring
! Output frequency (speed) .. Binary in 0.01Hz (1r/min) increments (FR-A500/F500 series)
Running speed................... Binary in 1r/min [FF=0], 0.1r/min [FF=1] increments
! Output current.................... Binary in 0.1A increments
! Output voltage ................... Binary in 0.1V increments
! Special monitor .................. For details, refer to the Inverter Instruction Manual.
! Alarm definition .................. Binary (up to eight most recent alarms)
Operation command
(Signal name)
Running(RUN)*
Forward running
Reverse running
Up to frequency(SU)*
Overload(OL)*
Instantaneous power failure(IPF)*
Frequency detection(FU)*
Alarm occurrence(ABC)*
FREQROL-V500 Series
Terminal
symbol
—
—
—
DO1
DO2
DO3 Instantaneous power failure(IPF)*
—
ABC
17
Operation command
(Signal name)
Running(RUN)
Forward running
Reverse running
Running(RUN)*
Up to speed(SU)*
Speed detection(FU)
Alarm occurrence(ABC)*
