Introducing the ZoneFlex Access Point
Getting to Know the Access Point Features
The external antenna connectors are for indoor use only. Do not connect
CAUTION:
them to outdoor antennas.
Table 4. ZoneFlex 2942/7942 rear panel elements
Number Item Name
1 Power
2 Lock Hasp
3 External RP-SMA
Connector
4 LAN Ports
5 OPTIONAL Button Not active in this model at this time.
6 SOFT RESET
Button
Table 5. Behavior of Ethernet port LEDs on ZoneFlex 2942/7942
LEDs
Off
Steady flashing Amber + Green Connected to 10Mbps device
Steady flashing Amber
Steady flashing Green
Intermittent flashing Amber +
Green
Intermittent flashing Amber
Intermittent flashing Green
Description
Connect the power adapter to this socket. (Input
110-240V AC, Output 12V 1.0A DC). Power can also
be supplied via 10/100 PoE port.
The lock hasp works with a cable or Ruckus mounts.
The recommended lock type is Masterlock 120 series
(D, T, Q, KAD types).
• ZoneFlex 2942: One external antenna connector
• ZoneFlex 7942: None
• ZoneFlex 2942: Two RJ-45 ports, supporting 10/
100 PoE (Power over Ethernet) and 10/100Mbps
connections.
• ZoneFlex 7942: Two RJ-45 ports, supporting 10/
100/1000 PoE (Power over Ethernet) and 10/100/
1000Mbps connections.
Each Ethernet port has two LEDs, which indicate the
type of device that is connected to the port.
Used to reset the AP. This is a normal reset and does
not reset the AP back to factory defaults.
Description
Not connected
Connected to 100Mbps device
Connected to 1000Mbps device
Connected to 10Mbps device, and passing traffic
Connected to 100Mbps device, passing traffic
Connected to 1000Mbps device, passing traffic
6
