Introducing the ZoneFlex Access Point
Getting to Know the Access Point Features
Table 3. ZoneFlex 2942/7942 side panel elements
Number LED/Button Name Description
2 DIR LED
3 AIR LED
4 WLAN LED
5 HARD RESET
Button
6 Sliding Door
• Off: The Access Point is not being managed by
ZoneDirector (standalone mode).
• Green: The Access Point is being managed by
ZoneDirector.
• Slow flashing green (one flash every two seconds):
The Access Point is being managed by
ZoneDirector, but is currently unable to
communicate with ZoneDirector.
• Fast flashing green (two flashes every second):
The Access Point is being managed by
ZoneDirector and is currently receiving
configuration settings (provisioning) or a firmware
update.
• Off: The WLAN service is down.
• Green: The AP is functioning as a Root AP (RAP)
or Mesh AP (MAP), and the uplink signal is good.
• Slow flashing green (one flash every two seconds):
Mesh networking is enabled, but the AP is still
searching for a mesh uplink.
• Fast flashing green (two flashes every second):
The Access Point is functioning as a Mesh AP and
the wireless signal to its uplink AP is fair.
• Off: The WLAN service is down.
• Amber: The WLAN is up, but no clients are
associated and no downlink MAPs are connected.
• Green: The WLAN is up and at least one client is
associated. No downlink MAPs are connected.
• Slow flashing green (one flash every two seconds):
The WLAN is up and at least one downlink MAP
is connected. No clients are associated.
• Fast flashing green (two flashes every second):
The WLAN is up, at least one downlink MAP is
connected, and at least one client is associated.
Pushing and quickly releasing this button reboots
the AP. Pushing and holding it for six seconds resets
the AP to factory defaults.
Protects the ports, buttons, and connector on rear
panel
