Summary of Contents for Fujitsu Siemens Computers SCENIC W

  • Page 1 Operating manual SCENIC W English...
  • Page 2 ... any technical problems or other questions which you would like to be clarified? Please contact: ● your sales partner ● your sales outlet Further information can be found in the "Safety", "Ergonomics" and "Warranty" manuals. The latest information on our products, tips, updates, etc., can be found on the internet under: http://www.fujitsu-siemens.com...
  • Page 4 Herausgegeben von/Published by Fujitsu Siemens Computers GmbH AG 1004 10/04 Ausgabe/Edition 3 Bestell-Nr./Order No.: A26361-K666-Z120-1-7619...

  • Page 5: Operating Manual

    Introduction Important notes SCENIC W Preparing for use Operation Troubleshooting and tips Operating manual System expansions Technical data Index October 2004 edition...
  • Page 6 SCENIC is a registered trademark of Fujitsu Siemens Computers GmbH. Microsoft, MS, MS-DOS, Windows, and Windows NT are registered trademarks of Microsoft Corporation. VESA and DPMS are trademarks of Video Electronics Standards Association. PS/2 is a registered trademark of International Business Machines, Inc.

  • Page 7: Table Of Contents

    Contents Your SCENIC W..........................1 Overview of product features ......................2 Notational conventions ........................3 Important notes ..........................5 Safety notes ............................5 Energy saving, disposal and recycling ..................5 CE marking..........................5 FCC Class B Compliance Statement....................6 Transporting the PC...........................6 Cleaning the PC ..........................6 Preparing for use..........................7 Unpacking and checking the delivery....................7...
  • Page 8 Contents Troubleshooting and tips ......................29 Installing new software ........................29 Power-on indicator remains unlit after you have switched on your device ........29 The screen stays blank ........................30 No mouse pointer displayed on the screen ..................31 The floppy disk cannot be read or written ..................31 Time and/or date is not correct......................

  • Page 9: Your Scenic W

    Your SCENIC W..is available with various configuration levels with different hardware and software. In addition, you can install accessible drives (e.g. DVD drive), hard disks and other boards. This manual tells you how to put your PC into operation and how to operate it in daily use. This manual applies for all configuration levels.

  • Page 10: Overview Of Product Features

    Your SCENIC W... Overview of product features The overview shows the most important product features (standard configurations. Since Fujitsu Siemens Computers adjusts the systems to suit customer requirements, the product features may not match those of your system. SCENIC W6xx Mechanical access protection Device for "Kensington Lock"...

  • Page 11: Notational Conventions

    Your SCENIC W... Notational conventions The meanings of the symbols and fonts used in this manual are as follows: indicates information which is important for your health or for preventing physical damage. indicates important information which is required to use the system properly.

  • Page 13: Important Notes

    Important notes In this chapter you will find information regarding safety which is essential to take note of when working with your PC. Safety notes Pay attention to the information provided in the "Safety" manual and in the following security notes. During installation and before operating the device, please observe the instructions on environmental conditions in the "Technical data"...

  • Page 14: Fcc Class B Compliance Statement

    ● Consult the dealer or an experienced radio/TV technician for help. Fujitsu Siemens Computers GmbH is not responsible for any radio or television interference caused by unauthorised modifications of this equipment or the substitution or attachment of connecting cables and equipment other than those specified by Fujitsu Siemens Computers GmbH. The correction of interferences caused by such unauthorised modification, substitution or attachment will be the responsibility of the user.

  • Page 15: Preparing For Use

    Preparing for use Please take note of the safety information in the "Important notes" chapter. Unpacking and checking the delivery It is recommended not to throw away the original packaging material! It may be required for reshipment at some later date. ►...

  • Page 16: Setting Up The Pc

    Preparing for use Setting up the PC When installing your PC, give consideration to the recommendations and safety notes in the "Safety" manual. Set up the PC only in its correct orientation. The points to observe are illustrated on the following pages.

  • Page 17: Connecting The Monitor

    Preparing for use Connecting the monitor ► Follow the instructions contained in the monitor manual to prepare the monitor for operation (e.g. connecting cables). ► Plug the data cable into the monitor port of the PC. ► Depending on the connector supplied with your monitor, plug the monitor's power cable into either the PC (1) or the mains supply (2).

  • Page 18: Connecting The Mouse

    Preparing for use Connecting the mouse Depending on the equipment level selected, your PC will be supplied with a PS/2 mouse or a USB mouse. Connecting a PS/2 mouse ► Connect the PS/2 mouse to the PS/2 mouse port of the PC. Connecting USB mouse ►...

  • Page 19: Connecting The Pc To The Mains Voltage

    Preparing for use Connecting the PC to the mains voltage 100 V - 125 V 200 V - 240 V a = Notch for inserting the screwdriver ► Check the voltage setting. Some units have a wide-range power supply, depending on the configuration level. This means that manual voltage setting is not necessary for these devices.
  • Page 20 Preparing for use ► Connect the power cable to the PC (1). ► Plug the power plug into the grounded mains outlet (2). A26361-K666-Z120-1-7619, edition 3...

  • Page 21: Initial Switch-On: Software Will Be Installed

    Preparing for use Initial switch-on: Software will be installed If the PC is connected to a network, the network protocol is required as well as the user and server details. Contact your network administrator if you have any questions about these settings. When you switch on your PC for the first time, the supplied software is installed and configured.

  • Page 22: Installing The Software

    Preparing for use 1 = Main power switch 0 = PC is switched off 2 = ON/OFF switch I = PC is ready-to-operate ► Switch the PC on with the main power switch on the back panel. ► Press the ON/OFF switch on the front of the PC. The corresponding indication then appears on the LCD or the relevant indicators light (see chapter "Indicators on the PC").

  • Page 23: Connecting External Devices

    Preparing for use Connecting external devices Read the documentation on the external device before connecting it. The power plug must be removed before connecting external devices, apart from USB devices. Do not either connect or disconnect cables during storms. Always take hold of the actual plug. Never unplug a cable by pulling the cable itself. Connect and disconnect the cables in the order described below.

  • Page 24: Ports On The Pc

    Preparing for use Ports on the PC The ports for external devices are on the rear and on the front of the PC. The ports available on your PC depend on the configuration level you have selected. The standard ports are marked with the symbols shown below (or similar).

  • Page 25: Connecting External Devices To The Parallel Port

    Preparing for use Connecting external devices to the parallel port External devices can be connected to the parallel port (e.g. a printer). ► Connect the data cable to the external device. ► Connect the data cable to the parallel port For an exact description of how to connect external devices to the parallel port, please see the device documentation.

  • Page 27: Operation

    Operation Switching on the PC ► If necessary, switch the monitor on (see the operating manual for the monitor). ► Switch the PC on with the main power switch on the rear of the PC. ► Press the ON/OFF switch on the front of the PC. The corresponding indication appears on the LCD (see section "Indicators on the PC").

  • Page 28: Indicators On The Pc

    Operation Indicators on the PC The indicators are on the front of the PC. Which indicators are available on your PC depends on the configuration level you have selected. 1 = LCD 2 = CD-ROM indicator 3 = Floppy disk indicator 1 - LCD The LCD lights up as soon as the PC is switched on.

  • Page 29: Keyboard

    Operation LAN connection appears on the LCD as soon as the PC is connected to a LAN. LAN access appears on the LCD as soon as the PC sends or receives data over the LAN. Message Appears on the LCD when an incoming message (mail, fax) is waiting. This symbol only appears if you use software that supports this function.

  • Page 30: Important Keys And Key Combinations

    Operation Important keys and key combinations The following description of keys and key combinations refers to MS Windows. Details of other keys and key combinations can be found in the documentation of the relevant application programme. ON/OFF switch (optional) Depending on the setting in the BIOS Setup, the system can be switched on, off, or on and off with this button.

  • Page 31: Working With Floppy Disks

    Operation Working with floppy disks Follow the instructions supplied by the vendor of the floppy disks. Never clean the floppy disk drives with cleaning disks. Any attempt would destroy the read/write head in the disk drive within 20 seconds. 1 = Insertion direction 2 = Label area 3 = Write protection tab for a 1.44 Mbyte floppy disk 4 = Identification of a 1.44 MB floppy disk or write protect switch on a 120 MB floppy disk...

  • Page 32: Settings In Bios Setup

    Operation Settings in BIOS Setup The BIOS Setup menu allows you to set your hardware configuration and system functions. When the PC is delivered, the default entries are valid (see "BIOS Setup" manual and if necessary technical manual for the mainboard). You may customise these settings to your requirements in the BIOS Setup.

  • Page 33: Anti-Theft Protection And Lead-Sealing

    Operation Anti-theft protection and lead-sealing There are three ways to protect your PC from theft: ● with the Kensington Lock device (3) and with a Kensington MicroSaver ● with a chain (lead-seal) ● with a (pad)lock To prevent unauthorised persons from opening the casing, the casing can be sealed. To do this, feed the sealing chain through the large eye (1) and the small eye (2) and seal the chain with the lead seal.

  • Page 34: Bios Setup Security Functions

    Operation BIOS setup security functions The Security menu in BIOS Setup offers you various options for protecting your personal data against unauthorised access, e.g.: ● Preventing unauthorised BIOS Setup entry ● Preventing unauthorised system access ● Preventing unauthorised access to the settings of boards with their own BIOS ●...
  • Page 35 Operation SystemLock permissions You can initialise a SmartCard with one of the following permissions: System The system starts following entry of the user PIN. You can change the user PIN. Setup You can open and change the BIOS Setup and change the user PIN. System+Setup The system starts following entry of the user PIN.

  • Page 37: Troubleshooting And Tips

    Troubleshooting and tips Take note of the safety notes in the "Safety" manual and in the "Preparing for use" chapter, when you connect or disconnect cables. If a fault occurs, try to correct it as described in the following places: ●...

  • Page 38: The Screen Stays Blank

    Troubleshooting and tips The screen stays blank If your screen remains blank this may be due to the following: Monitor is switched off ► Switch your monitor on. Power saving has been activated (screen is blank) ► Press any key on the keyboard. ►...

  • Page 39: No Mouse Pointer Displayed On The Screen

    Troubleshooting and tips Wrong monitor has been set under Window XP ► Restart the PC. ► Press F8 while the system is booting. Either the Windows Advanced Start Options menu or the menu for selecting the operating system appears. ► If the menu for selecting the operating system appears, press F8 .

  • Page 40: Time And/Or Date Is Not Correct

    Troubleshooting and tips Time and/or date is not correct You can set the time and date in the BIOS Setup or in the operating system. ► Set the time and date. If the time and date are repeatedly wrong when you switch on your PC, the on-board battery is flat.

  • Page 41: System Expansions

    System expansions As the PC has to be shut down in order to install/deinstall system hardware components, it is a good idea to print out the relevant sections of this chapter. It may be necessary to update the BIOS when carrying out a system expansion or hardware upgrade.

  • Page 42: Opening The Casing

    System expansions Opening the casing ► Switch the PC off. The PC must not be in the energy-saving mode. Please take note of the safety information in the "Important notes" chapter. Pull the power plug out of the mains outlet. Only insert the power plug after you have closed the casing.

  • Page 43: Closing The Casing

    System expansions Closing the casing ► Push the side cover from above in the direction of the arrow (1) until it engages. ► Lock the casing again if necessary. ► Return the system unit to its original position. ► Reconnect any disconnected cables (power cord, cables to external devices, etc.). A26361-K666-Z120-1-7619, edition 3...

  • Page 44: Installing And Removing A Board

    System expansions Installing and removing a board Please take note of the section "Information about boards". The number, position and arrangement of the board slots on the mainboard can be found in the technical manual for the mainboard. Boards may already be installed when the device is shipped. Installing a board ►...
  • Page 45 System expansions ► Take the new board out of its packaging. ► Make the required settings for the board. ► Push the board up to its slot (1). ► Press the board into the slot so that it engages. ► If necessary, connect the cables.

  • Page 46: Removing A Board

    System expansions Removing a board ► Open the casing (see "Opening the casing"). ► Disconnect the cables connected to the board. ► Press the unlocking mechanism (1) down and open the locking rail (2). The word "PRESS" is embossed on the unlocking mechanism. ►...
  • Page 47 System expansions ► Push the slot cover into the slot (1). Ensure that the projection (a) on the slot cover engages into the appropriate recess. If it does not, you will find it difficult to close the locking rail. There is a danger of damage. ►...

  • Page 48: Low-Profile Boards

    System expansions Low-Profile boards For units with a particularly low overall height, there are so-called low-profile boards with a slot cover with a lower overall height to match the low-profile units. To also install these low-profile boards in normal board slots, you must mount a corresponding slot adapter beforehand Two-piece rear covers are fitted into the slots intended for low-profile boards.

  • Page 49: Installing And Removing Drives

    System expansions Installing and removing drives The case offers space for ● four accessible drives (5¼" drives and 3½" drives) ● two inaccessible drives when using a 200 W powersupply or four inaccessible drives when using a 300 W powersupply (3½" drives). "Accessible drives"...

  • Page 50: Attaching The Front Panel

    System expansions ► Detach the plastic hook on the front panel of the casing and carefully remove the front panel. If you pull too hard, you may loosen or damage the LCD cable. The cable of the LCD is long enough that you can carefully place it to one side with the front panel.

  • Page 51: Installing An Accessible Drive

    System expansions Installing an accessible drive ► Open the casing (see "Opening the casing"). ► Remove the front (see "Removing the front panel"). ► Press the EasyChange rails (1) together and pull the empty slide-in module out of the casing (2). ►...
  • Page 52 System expansions ► Take the new drive out of its packaging. ► Adjust the required settings on the drive (if necessary, on already-installed drives as well). ► Press the EasyChange rails into the provided holes. ► Push the accessible drive into the casing until the EasyChange rails engage. ►...

  • Page 53: Removing An Accessible Drive

    System expansions ► Close the casing (see "Closing the casing"). With the upper three accessible drives, the EasyChange rail is attached at the bottom of the module. The rail is attached at the center of the module on the lowest drive. All rails are mounted correctly on delivery.
  • Page 54 System expansions ► Pull the EasyChange rails off the drive. ► Press the EasyChange rails into the holes provided in the empty slide-in module. A26361-K666-Z120-1-7619, edition 3...

  • Page 55: Changing The Floppy Disk Drive

    System expansions ► Slide the slide-in module into the casing until it engages noticeably. ► Attach the front panel (see "Attaching the front panel"). ► Close the casing (see "Closing the casing"). It may be necessary to modify the entry for the remaining drives in the BIOS Setup. Changing the floppy disk drive ►...
  • Page 56 System expansions Removing the floppy disk drive ► Press the EasyChange rails in the direction of the arrows (1). ► Pull the floppy disk slide-in module out of the casing (2). ► Pull the EasyChange rails off the floppy disk slide-in module. A26361-K666-Z120-1-7619, edition 3...
  • Page 57 System expansions ► Remove the screws (1) on both sides of the slide-in module. ► Pull the disk drive out of the slide-in module (2). Installing the floppy disk drive ► Take the new floppy disk drive out of its packaging. ►...
  • Page 58 System expansions ► Press the EasyChange rails into the provided holes. ► Slide the floppy disk slide-in module into the casing (1) until it engages noticeably. ► Fit the data and power supply connectors to the floppy disk drive. ► If it is present, pull the cable of the front USB or USB-audio interface from the mainboard (see also the technical manual for the mainboard).

  • Page 59: Installing Or Removing The Hard Disk Drive

    System expansions Installing or removing the hard disk drive ► Open the casing (see "Opening the casing"). Removing the cover ► Loosen the screw (1). ► Fold out the cover (2). Installing a hard disk drive Dependent on which casing version you have a serial ATA hard disk can only be installed in the upper three slots.
  • Page 60 System expansions ► Push the hard disk drive into the casing (1) until the EasyChange rails engage. ► Connect the data and power supply cables to the hard disk drive or to the hard disk drives. IDE interface: Connect the blue plug of the data cable to the connection on the mainboard. Connect the plug on the other end to the hard disk drive.
  • Page 61 System expansions Installing the cover plate ► Set the cover plate into the casing such that the projections (a) engage into the appropriate recesses (1). ► Close the cover and fasten it with the screw (2). ► Close the casing (see "Closing the casing"). It may be necessary to modify the entry for the drive in the BIOS Setup.
  • Page 62 System expansions Removing a hard disk drive ► Open the casing (see "Opening the casing"). ► Remove the cover (see "Removing the cover "). ► Disconnect all cables connected to the drive (data cable, power supply cable). ► Press the EasyChange rails in the direction of the arrows (1). ►...

  • Page 63: Replacing The Smartcard Reader

    System expansions Replacing the SmartCard reader Removing a SmartCard reader ► Open the casing (see "Opening the casing"). ► Remove the front (see "Removing the front panel"). ► Disconnect the plug of the SmartCard data cable from the mainboard (see also the technical manual for the mainboard).
  • Page 64 System expansions Installing a SmartCard reader ► Slide the SmartCard reader into the supplied mounting (1) with the component side upwards and fix it in place with the screws (2). ► Connect the data cable to the SmartCard reader. ► Place the carrier on the guide clips in the casing.

  • Page 65: Installing And Removing Front Usb Or Usb Audio Ports

    System expansions Installing and removing front USB or USB audio ports You can install the following variants in the recess next to the floppy disk drive: ● two USB ports ● or a USB port combined with two audio ports ●...
  • Page 66 System expansions ► Pull the EasyChange rails off the floppy disk slide-in module. ► Detach the locking mechanisms (1) and remove the front bezel of the floppy disk slide-in module (2). ► Remove the blanking plate from the slide-in module bezel (3). A26361-K666-Z120-1-7619, edition 3...
  • Page 67 System expansions ► Slide the USB or USB-audio interface through the hole provided (1). First slide the tongue into the upper opening. ► Fasten the USB or USB audio ports with the screw (2). ► If appropriate insert the interface frame into the slide-in module bezel (1). ►...
  • Page 68 System expansions ► Press the EasyChange rails into the provided holes. ► Slide the floppy disk slide-in module into the casing (1) until it engages noticeably. Fit the data and power supply connectors to the floppy disk drive. ► Connect the USB cable and, if necessary, the audio cable to the corresponding connector on the mainboard (see also the technical manual for the mainboard).
  • Page 69 System expansions Removing front USB or USB audio ports ► Open the casing (see "Opening the casing"). ► Remove the front (see "Removing the front panel"). ► Detach the USB data cable and, if present, the audio data cable from the mainboard (see the technical manual for the mainboard).
  • Page 70 System expansions ► Detach the locking mechanisms (1) and remove the bezel of the floppy disk slide-in module (2). ► If appropriate remove the interface frame from the bezel of the floppy disk slide-in module (3). ► Remove the screw (1) and then remove the USB or USB-audio interface (2). A26361-K666-Z120-1-7619, edition 3...
  • Page 71 System expansions ► Insert the blanking plate into the slide-in module bezel (1). ► First attach the bezel at the bottom and then push the upper tongues into place until they engage (2). ► Press the EasyChange rails into the provided holes. A26361-K666-Z120-1-7619, edition 3...
  • Page 72 System expansions ► Slide the floppy disk slide-in module into the casing (1) until it engages noticeably. ► Fit the data and power supply connectors to the floppy disk drive. ► Attach the front panel (see "Attaching the front panel"). ►...

  • Page 73: Installing Wlan Module

    System expansions Installing WLAN module ► Open the casing (see "Opening the casing"). ► Remove the front (see "Removing the front panel"). ► Detach the USB data cable and, if present, the audio data cable from the mainboard (see the technical manual for the mainboard).
  • Page 74 System expansions ► First attach the bezel at the bottom and then push the upper tongues into place until they engage (2). ► Press the EasyChange rails into the provided holes. A26361-K666-Z120-1-7619, edition 3...
  • Page 75 System expansions ► Slide the slide-in module into the casing until it engages noticeably. ► Connect the USB data cable of the WLAN module onto the corresponding connector on the mainboard (also see "Technical Manual" for the mainboard). ► Attach the front panel (see "Attaching the front panel"). ►...

  • Page 76: Removing Wlan Module

    System expansions Removing WLAN module ► Open the casing (see "Opening the casing"). ► Remove the front (see "Removing the front panel"). ► Detach the USB data cable of the WLAN module and, if present, the audio data cable from the mainboard (see the technical manual for the mainboard).
  • Page 77 System expansions ► Detach the locking mechanisms (1) and remove the bezel (2). ► Remove the screws on both sides of the slide-in module (1). ► Pull the WLAN module out of the slide-in module (2). A26361-K666-Z120-1-7619, edition 3...
  • Page 78 System expansions ► First attach the bezel at the bottom (1) and then push the upper tongues into place until they engage (2). ► Press the EasyChange rails into the provided holes. A26361-K666-Z120-1-7619, edition 3...
  • Page 79 System expansions ► Slide the slide-in module into the casing until it engages noticeably. ► Attach the front panel (see "Attaching the front panel"). ► Close the casing (see "Closing the casing"). A26361-K666-Z120-1-7619, edition 3...

  • Page 80: Extensions To The Mainboard

    System expansions Extensions to the mainboard Details on whether you can upgrade the main memory or the processor are provided in the technical manual for the mainboard. In order to upgrade or replace the processor, you must first remove the ventilation cover.

  • Page 81: Replacing Lithium Battery

    System expansions Replacing lithium battery In order to permanently save the system information, a lithium battery is installed to provide the CMOS-memory with a current. A corresponding error message notifies the user when the charge is too low or the battery is empty. The lithium battery must then be replaced. Incorrect replacement of the lithium battery may lead to a risk of explosion! The lithium battery may be replaced only with an identical battery or with a type recommended by the manufacturer.

  • Page 83: Technical Data

    ● right-hand side min. 200 mm ● front min. 200 mm ● rear min. 200 mm The data sheet of the PC contains further technical data. You will find the data sheet on the internet at http://www.fujitsu-siemens.com/ A26361-K666-Z120-1-7619, edition 3...

  • Page 85: Index

    Index 3 1/2-inch drive 41 5 1/4-inch drive 41 Data protection 24 Date not correct 32 Device drivers Access permission, SmartCard 26 parallel port 17 Alt Gr key 22 serial port 16 Anti-theft protection 25 USB 17 Audio input 16 Devices Audio output 16 connecting 15, 16, 17...
  • Page 86 Index Floppy disk drive changing 47 LAN port 16 indicator 21 LCD 20 installing 49, 50 Lead-sealing 25 removing 48 Line in 16 Function keys 21 Line out 16 Lithium battery 72 replacing 73 Lock 24 Hard disk contents, restoring 32 Low-profile boards 40 Hard disk drive mounting slot adapter 40...
  • Page 87 Index Power-on indicator 14 ON/OFF switch 14, 22 dark 29 fails to light 29 Preparing for first use, overview 7 Preparing for use 7 Packing material 7 overview 7 unpacking 7 Printer 16 Parallel port 16 Processor 72 connecting devices 17 Property protection 24 settings 17 Protection...
  • Page 88 Index USB mouse, connecting 10 Technical data 75 USB port 10, 17 Time connecting devices 17 not correct 32 USB port or USB audio port Time, daylight savings 32 installing 57 Tips 29, 32 USB ports Transport 6 removing 61 Trouble USB, port 16 floppy disk 31...
