Related Manuals for Fujitsu Siemens Computers SCENIC S 2

Summary of Contents for Fujitsu Siemens Computers SCENIC S 2

  • Page 1 Operating Manual SCENIC S 2 English...
  • Page 2 Please contact: • your sales partner • your sales outlet Further information can be found in the "Safety and Ergonomics" and "Warranty" manuals. The latest information on our products, tips, updates, etc., can be found on the internet under: http://www.fujitsu-siemens.com...
  • Page 4 Este manual ha sido impreso sobre papel reciclado. Questo manuale è stato stampato su carta da riciclaggio. Denna handbok är tryckt på recyclingpapper. Dit handboek werd op recycling-papier gedrukt. Published by Fujitsu Siemens Computers GmbH A26361-K650-Z100-1-7619 Order No.: Printed in the Federal Republic of Germany AG 0303...

  • Page 5: Operating Manual

    Introduction Important notes SCENIC S 2 Preparation for use and operation Troubleshooting and tips System expansions Operating manual Technical data Index March 2003 edition...
  • Page 6 All other trademarks referenced are trademarks or registered trademarks of their respective owners, whose protected rights are acknowledged. Copyright  Fujitsu Siemens Computers GmbH 2003 All rights, including rights of translation, reproduction by printing, copying or similar methods, in part or in whole, are reserved.

  • Page 7: Table Of Contents

    Contents Introduction .............................1 Notational conventions ........................1 Important notes ..........................3 Safety notes ............................3 Manufacturer’s notes .........................3 Energy saving, disposal and recycling ..................3 CE marking..........................3 FCC Class B Compliance Statement ..................4 Transporting the PC...........................4 Cleaning the PC ..........................5 Preparation for use and operation ....................7 Unpacking and checking the delivery....................7 Setting up the PC ..........................8 Changing operating position to vertical or horizontal..............9...
  • Page 8 Contents Troubleshooting and tips ......................29 Installing new software........................29 Power-on indicator remains unlit after you have switched on your device ........29 The screen stays blank ........................30 Flickering stripes across the monitor ....................31 No screen display or display drifts....................31 No mouse pointer displayed on the screen ..................

  • Page 9: Introduction

    Introduction This operating manual tells you how to put your PC into operation and how to operate it in daily use. In addition, you can install accessible drives and additional boards. An optional board for an audio/USB control panel on the front of the PC offers convenient access to audio and USB interfaces and increases their number.

  • Page 11: Important Notes

    Important notes In this chapter you will find information regarding safety which is essential to take note of when working with your PC. Safety notes This device complies with the relevant safety regulations for data processing equipment. If you have any questions, contact your sales outlet.

  • Page 12: Fcc Class B Compliance Statement

    • Consult the dealer or an experienced radio/TV technician for help. Fujitsu Siemens Computers GmbH is not responsible for any radio or television interference caused by unauthorised modifications of this equipment or the substitution or attachment of connecting cables and equipment other than those specified by Fujitsu Siemens Computers GmbH The correction of interference caused by such unauthorised modification, substitution or attachment will be the responsibility of the user.

  • Page 13: Cleaning The Pc

    Cleaning the PC Important notes Cleaning the PC Turn off all power and equipment switches and remove the power plug from the mains supply. Do not clean any interior parts yourself, leave this job to a service technician. To avoid damaging the casing, do not use any abrasive powder, or other cleaning agents that damage plastic.

  • Page 15: Preparation For Use And Operation

    Preparation for use and operation Please pay careful attention to the safety information provided in the "Important notes" chapter and in the "Safety and Ergonomics" manual. Unpacking and checking the delivery We recommend that you retain the original packaging material, as it may be required for transportation at a later date.

  • Page 16: Setting Up The Pc

    Preparation for use and operation Setting up the PC Setting up the PC When installing your PC, give consideration to the recommendations on video workstation ergonomics in the "Safety and Ergonomics" manual. Do not expose the PC to extreme environmental conditions (see "Technical data" chapter) and protect it from dust, humidity and heat.

  • Page 17: Changing Operating Position To Vertical Or Horizontal

    Setting up the PC Preparation for use and operation Changing operating position to vertical or horizontal Aligning the logo (if desired): Ê Open the casing (see "Opening the casing"). Ê Release the locking lugs on the front cover. Ê Remove the front panel by lifting it upwards. Ê...
  • Page 18 Preparation for use and operation Setting up the PC Ê Set up the PC on end so that the ON/OFF switch is located at the bottom. Ê Fit the base plate with the stand-up feet on the accessible narrow side of the cover. Please note: Thread the rubber feed on the surface of the cover into the guide rails of the stand-up feet.
  • Page 19 Setting up the PC Preparation for use and operation Ê Turn over the PC and set it up so that the ON/OFF switch is located at the top. Never operate the PC in the vertical operation position without the base plate (fire protection).
  • Page 20 Preparation for use and operation Setting up the PC Changing operating position to horizontal: Ê Turn over the PC and set it up so that the ON/OFF switch is located at the bottom. Ê Pull off the base plate with the stand-up feet upward. Ê...

  • Page 21: Connecting Devices

    Connecting devices Preparation for use and operation Connecting devices The power plug must be disconnected! Do not connect or disconnect cables during a thunderstorm (risk of electric shock). Always take hold of the actual plug. Do not pull the cable which could damage the plug or the socket! Read the documentation on the external device before connecting it.

  • Page 22: Ports For External Devices

    Preparation for use and operation Connecting keyboard and mouse Ports for external devices The ports for external devices are on the rear and on the front of the casing. The ports available on your device depend on the configuration level you have selected. The standard ports are marked with the symbols shown below (or similar).

  • Page 23: Connecting The Mouse

    Connecting keyboard and mouse Preparation for use and operation Connecting standard keyboard Use the supplied keyboard cable only. Ê Plug the round keyboard cable connector into the port marked with this symbol on the system unit. Ê Plug the other end of the keyboard cable (square plug) into the socket on the underside of the keyboard.

  • Page 24: Connecting The Monitor To The Electricity Supply

    Preparation for use and operation Connecting keyboard and mouse Connecting the monitor to the electricity supply Ê Follow the instructions contained in the monitor manual to prepare the monitor for operation. Ê Plug the data cable of the monitor into the monitor port of the PC. Ê...

  • Page 25: Connecting The Pc To The Mains Voltage

    Connecting the PC to the mains voltage Preparation for use and operation Connecting the PC to the mains voltage 1 = Notch for inserting the screwdriver Ê Check the voltage setting. The value marked with an arrow must agree with the local mains voltage: 115 = 100 V to 127 V 230 = 200 V to 240 V If the voltage setting is incorrect:...

  • Page 26: Locking/Unlocking The Pc

    Preparation for use and operation Locking/Unlocking the PC Locking/Unlocking the PC You can use the lock on the casing to physically lock the system unit. Locking the system unit Ê Turn the key anticlockwise (1). Unlocking the system unit Ê Turn the key clockwise (2).

  • Page 27: Switching The Pc On And Off

    Switching the PC on and off Preparation for use and operation Switching the PC on and off 1 = Main power switch 0 = PC is switched off 2 = ON/OFF switch I = PC is ready-to-operate 3 = Power-on indicator A26361-K650-Z100-1-7619...

  • Page 28: Switching On The Pc For The First Time

    Preparation for use and operation Switching the PC on and off Switching on the PC for the first time If the PC is connected to a network, the network protocol is required as well as the user and server details. Contact your network administrator if you have any questions about these settings.

  • Page 29: Switching On The Pc

    Switching the PC on and off Preparation for use and operation Switching on the PC Ê Switch the monitor on (see the operating manual for the monitor). Ê Switch the PC on with the main power switch on the back panel. Ê...

  • Page 30: Indicators On The Pc

    Preparation for use and operation Indicators on the PC Indicators on the PC 1 = CD-ROM indicator 5 = Hard disk indicator 2 = SmartCard reader indicator 6 = Message indicator 3 = Floppy disk indicator 4 = Power-on indicator 1 –...
  • Page 31 Indicators on the PC Preparation for use and operation 4 – Power-on indicator • The indicator lights green: The PC is switched on. • The indicator lights up orange or flashes: The PC is ready-to-operate or in energy-saving mode. After being switched on with the power button, the PC switches on or returns to the state it was in before the energy-saving mode.

  • Page 32: Working With Floppy Disks

    Preparation for use and operation Working with floppy disks Working with floppy disks Follow the instructions supplied by the vendor of the floppy disks. Never clean the floppy disk drives with cleaning disks. Any attempt would destroy the read/write head in the disk drive within 20 seconds. 1 = Insertion direction 2 = Label area 3 = Write protection switch for a 720 KB or a 1.44 MB floppy disk...

  • Page 33: Keyboard

    Keyboard Preparation for use and operation Keyboard 1 = Function keys 4 = Cursor keys 2 = Power button (optional) 5 = Numeric keypad (calculator keypad) 3 = Alphanumeric keypad The illustrated keyboard is an example and may differ from the model you use. Important keys and key combinations The following description of keys and key combinations refers to MS Windows.

  • Page 34: Settings In Bios Setup

    Preparation for use and operation Settings in BIOS Setup Shift key enables upper-case letters and the upper key symbols to be used. Alt Gr (e.g. German keyboard) Alt Gr produces a character shown on the right-hand side of a key (e.g. the character "\" on the key [ß]).

  • Page 35: Property And Data Protection

    Property and data protection Preparation for use and operation Property and data protection Your PC enables you to protect your system and personal data against unauthorised access in a number of ways. By combining these options, you can achieve maximum protection for your system. Locking the system unit You can use the lock on the casing to physically lock the system unit (see "Locking/Unlocking the PC").

  • Page 36: Cover Monitoring (Intrusion Detection)

    Property and data protection Cover monitoring (Intrusion Detection) In your SCENIC S 2 a casing switch monitors the removal of the casing top cover. If you use software like DeskView, the opening of the casing (time, duration) will be reported.

  • Page 37: Troubleshooting And Tips

    Troubleshooting and tips Take note of the safety notes in the "Safety and Ergonomics" manual and in the "Preparation for use and operation" chapter, when you connect or disconnect cables. If a fault occurs, try to correct it as described in the following places: •...

  • Page 38: The Screen Stays Blank

    Troubleshooting and tips The screen stays blank If your screen remains blank this may be due to the following: Monitor is switched off Ê Switch your monitor on. Power cable or monitor cable not connected Ê Switch off the monitor and the PC. Ê...

  • Page 39: Flickering Stripes Across The Monitor

    Troubleshooting and tips Wrong monitor has been set under Windows 2000 Ê Restart the PC. Ê If the message Starting Windows appears, press function key [F8]. The Windows 2000 Advanced Options Menu appears. Ê Select Safe Mode or Safe Mode with Network. Ê...

  • Page 40: No Mouse Pointer Displayed On The Screen

    Troubleshooting and tips No mouse pointer displayed on the screen Ê Shut down the operating system properly. Ê Switch the PC off. Ê Check that the mouse cable is properly connected to the system unit. If you use an adapter or extension lead with the mouse cable, check the connections. Ê...

  • Page 41: Forgotten Bios Password

    Troubleshooting and tips Forgotten BIOS password If you have forgotten a BIOS password, contact our help desk. Error messages on the screen Error messages and their descriptions are listed in the technical manual for the mainboard or in the "BIOS Setup" manual and in the documentation of the installed software. Restoring the hard disk contents Should you need to restore your hard disk, the instructions are provided on the cover of the "Recovery CD"...

  • Page 43: System Expansions

    System expansions It may be necessary to update the BIOS when carrying out a system expansion or hardware upgrade. When installing components, make sure that the maximum permissible temperatures of the individual components are not exceeded. The device must be switched off when installing/removing system expansions, it must not be in an energy saving mode.

  • Page 44: Opening The Casing

    System expansions Opening the casing Ê Switch the PC off. Please take note of the safety information in the "Important notes" chapter. Remove the plug from the mains outlet so that the system is totally disconnected from the electricity supply! Ê...

  • Page 45: Closing The Casing

    System expansions Closing the casing Ê Place the top cover on the casing base (1) so that the distance (a) is approximately 10 mm. Ê Push the top cover in the direction of the arrow (2) until it engages. Ê Lock the casing by pushing the locking slide (3) to the right in the direction of the arrow ("close") past a slight resistance until it engages.

  • Page 46: Installing And Removing A Board

    System expansions Installing and removing a board The number, position and arrangement of the board slots on the mainboard can be found in the technical manual for the mainboard. Boards may already be installed when the device is shipped. The retainers of the slot on the mainboard can differ from the one in the model described in the following.
  • Page 47 System expansions Ê Pull the rear slot cover plate out of the slot. Do not dispose of the cover plate. For cooling, protection against fire and in order to comply with EMC regulations, you must refit the cover plate if you remove the board. Ê...
  • Page 48 System expansions Ê Press the board evenly into the slot so that it engages. Make sure that the tip of the metal angle bracket of the board engages on the inside of the casing. Ê Release the retainer. Make sure that the locking lug of the retainer (a) engages in the corresponding guide of the board.

  • Page 49: Removing Board With Slotfix

    System expansions Removing board with Slotfix Ê Open the casing (see "Opening the casing"). Ê Disconnect the cables connected to the board. Ê Press the tab of the Slotfix clip and hold it down (1). Ê Unhook the locking lug on the tab of the Slotfix clip from the eye in the casing (2). Ê...
  • Page 50 System expansions Ê Press the retainer of the slot on the mainboard in the direction of the arrow (1) until the locking lug (a) is released and hold it down. Ê Pull the board evenly out of the slot (2). Ê...

  • Page 51: Installing Board With Screw

    System expansions Ê Close the casing (see "Closing the casing"). If you have installed or removed a PCI board, please check the relevant PCI slot settings in the BIOS Setup. If necessary, change the settings. Further information is provided in the PCI board documentation.
  • Page 52 System expansions Ê Press the retainer of the slot on the mainboard in the direction of the arrow (1) and hold down. Ê Push the board into the bay (2) up to the slot. Ê Press the board evenly into the slot so that it engages. Make sure that the tip of the metal angle bracket of the board engages on the inside of the casing.

  • Page 53: Removing Board With Screw

    System expansions Removing board with screw Ê Open the casing (see "Opening the casing"). Ê Disconnect the cables connected to the board. Ê Remove the screw (1). Ê Press the retainer of the slot on the mainboard in the direction of the arrow (2) until the locking lug (a) is released and hold it down.
  • Page 54 System expansions Ê Push the rear slot cover plate into the slot (1). Ensure that the point of the cover engages on the outside of the casing. Ê Fasten the rear slot cover plate with the screw (2). Ê Close the casing (see "Closing the casing"). If you have installed or removed a PCI board, please check the relevant PCI slot settings in the BIOS Setup.

  • Page 55: Board For Audio/Usb Front Panel

    System expansions Board for audio/USB front panel Your device can be upgraded with a board for an audio/USB front panel that offers you additional connections on the front of the casing: • an audio output: If this audio output on the front and the one on the back are used simultaneously, then the audio output on the front has priority.

  • Page 56: Installing And Removing Drives

    System expansions Installing and removing drives Installing and removing the drive cage Ê Open the casing (see "Opening the casing"). Removing the drive cage Ê Loosen the screws (1). Ê Disconnect the cables between the hard disk drive and the mainboard at the hard disk drive. The drive cage rests on the front cover in a guide with its longitudinal side facing the front cover.
  • Page 57 System expansions Ê Fold up the lever in the direction of the arrow and secure the drive cage with the lever (3). Make sure that the lever grips in the guide on the drive cage so that the drive cage cannot slip off.
  • Page 58 System expansions Installing the drive cage Ê Align the drive cage as shown in the illustration. Ê Insert the drive cage with its longitudinal side facing the front cover in the guide on the front cover. Hold the drive cage at an angle (1). Ê...
  • Page 59 System expansions Ê Remove the drive cage from the lever, hold the drive cage at an angle and fold the lever back into its initial position (1). Ê Lower the drive cage. Ê Secure the drive cage with the screws (2). Ê...

  • Page 60: Changing The Floppy Disk Drive

    System expansions Changing the floppy disk drive Ê Open the casing (see "Opening the casing"). Ê Remove the drive cage (see "Installing and removing the drive cage"). Ê Turn over the drive cage and place it on a flat surface with the accessible drives facing upward. Ê...

  • Page 61: Changing The Cd-Rom Drive

    System expansions Ê Install the drive cage (see "Installing and removing the drive cage"). Ê Close the casing (see "Closing the casing"). You may have to check the entry for the drive in the BIOS Setup. Changing the CD-ROM drive Ê...
  • Page 62 System expansions Ê Slide the drive into the drive cage (1). Ê Fasten the drive into place with the screws (2). Ê Install the drive cage (see "Installing and removing the drive cage"). Ê Close the casing (see "Closing the casing"). You may have to check the entry for the drive in the BIOS Setup.

  • Page 63: Replacing A Hard Disk Drive

    System expansions Replacing a hard disk drive Ê Open the casing (see "Opening the casing"). Ê Disconnect the cables between the hard disk drive and the mainboard at the hard disk drive. Ê Lightly press on the clips in the direction of the arrow (1). Ê...
  • Page 64 System expansions Ê Secure the EasyChange rails on the side of the hard disk by inserting the upper pins of the EasyChange rail in the corresponding holes of the hard disk. Ê Push the hard disk drive into the drive cage until the EasyChange rails engage (3). Ê...

  • Page 65: Extensions To The Mainboard

    System expansions Extensions to the mainboard Details of how and if you can upgrade the main memory or the processor of your PC are provided in the technical manual for the mainboard. In order to upgrade or replace the processor, you must first remove the ventilation cover.

  • Page 66: Replacing The Lithium Battery

    System expansions Replacing the lithium battery In order to permanently save the system information, a lithium battery is installed to provide the CMOS-memory with a current. A corresponding error message notifies the user when the charge is too low or the battery is empty. The lithium battery must then be replaced. Incorrect replacement of the lithium battery may lead to a risk of explosion.

  • Page 67: Technical Data

    Technical data Electrical data Regulations complied with: EN 60950 / VDE 0805 UL 1950 CSA 22.2 No.950 Protection class: Rated voltage range: (selectable) 100 V -127 V / 200 V -240 V Frequency: 50 Hz -60 Hz Max. rated current •...

  • Page 69: Index

    Index Connecting Access protection, MS-Windows 28 keyboard 14 Alphanumeric keypad 25 mouse 15 Alt Gr key 26 standard keyboard 15 Anti-theft protection USB keyboard 15 chaining 27 Contents of delivery Kensington Lock 27 unpacking 7 lead-seal 27 Control key 26 Audio input 14 Courier 1 Audio output 14...
  • Page 70 Index ESD 35 External devices Main memory 57 connecting 13 Mainboard, extensions 57 ports 14 Manuals, further 33 Memory, upgrading 57 Menu key 25 Message FCC statement 4 indicator 23 First time switching on 20 Microphone jack 14 Floppy disk Monitor cannot write 32 cleaning 5...
  • Page 71 Index Security functions aligning logo 9 access protection under Windows 28 cabling 13 Anti-theft protection 27 cannot be switched on 29 BIOS Setup 28 chaining 27 casing lock 27 cleaning 5 chaining 27 closing 37 cover monitoring 28 connecting 13, 17 Kensington Lock 27 lead-sealing 27 lead-seal 27...
  • Page 72 Index Ventilation area 59 Warm boot 26 Video workstation Weight 59 ergonomic 8 A26361-K650-Z100-1-7619...
