- Page 1 S C E N I C e D O P E R A T I N G M A N U A L...
- Page 2 Is there ..any technical problem or other question you need clarified? Please contact: • one of our service partners • your sales partner • your sales outlet The addresses of your service partners are contained in the guarantee booklet or in the service address booklet.
- Page 4 P r i n t e d i n t h e F e d e r a l R e p u b l i c o f G e r m a n y A G 0 2 0 0 0 2 / 0 0 A26361-K622-Z100-1-7619 SCENIC eD OPERATING MANUAL...
- Page 5 Introduction Important notes SCENIC eD Preparation for use and operation Troubleshooting and tips System expansions Operating Manual Technical data Index February 2000 edition...
- Page 6 All other trademarks referenced are trademarks or registered trademarks of their respective owners, whose protected rights are acknowledged. Copyright Fujitsu Siemens Computers GmbH 2000 ã All rights, including rights of translation, reproduction by printing, copying or similar methods, even of parts are reserved.
-
Page 7: Table Of Contents
Contents Introduction .............................1 Notational conventions ........................1 Important notes ..........................3 Safety ..............................3 Manufacturer’s notes .........................3 Energy saving..........................3 Disposal and recycling.......................4 CE certificate ..........................5 FCC Class B Compliance Statement....................5 Power cord selection .........................6 For the United States and Canada.....................7 For the United Kingdom......................8 Transporting the PC ..........................8 Cleaning the PC ..........................8 Preparation for use and operation .................... - Page 8 Contents System expansions........................33 Information on boards ......................33 Opening the system unit ......................... 34 Assembling the system unit ......................35 Installing a board..........................37 Installing and removing drives......................39 Installing an accessible 5 1/4-inch drive .................. 39 Removing an accessible 5 1/4-inch drive ................41 Changing the floppy disk drive ....................
-
Page 9: Introduction
Introduction This Operating Manual tells you how to put your PC into operation and how to operate it in daily use. This description applies for all configuration levels. Depending on the configuration level chosen some of the hardware components described may not be available on your PC. Please observe the notes on your operating system. -
Page 11: Important Notes
Important notes In this chapter you will find information regarding safety which it is essential to take note of when working with your PC. The manufacturer's notes contain helpful information on your PC. Safety This device complies with the relevant safety regulations for data processing equipment. If you have any questions, contact your sales outlet or our customer service center. -
Page 12: Disposal And Recycling
Any components not reclaimed will be disposed of in an environmentally acceptable manner. For devices marked with this symbol Fujitsu Siemens Computers GmbH offers a guarantee for 36 months with a Bring-in-Service. The guarantee starts on the day of delivery (sale date) by Fujitsu Siemens Computers GmbH or a Fujitsu Siemens partner. -
Page 13: Fcc Class B Compliance Statement
• Consult the dealer or an experienced radio/TV technician for help. Fujitsu Siemens Computers B V is not responsible for any radio or television interference caused by unauthorized modifications of this equipment or the substitution or attachment of connecting cables... -
Page 14: For The United States And Canada
Important notes Power cord selection For the United States and Canada Use a UL listed and CSA labeled cord set consisting of a three-conductor cord with a maximum length of 15 feet. For units that stand on a desk or table, type SVT or SJT cord sets shall be used. For units that stand on floor, only SJT type cord sets shall be used. -
Page 15: For The United Kingdom
Transporting the PC Important notes For the United Kingdom Should the plug on the flexible cord not be of the type for your socket outlets, do not use an adapter but remove the plug from the cord and discard. Carefully prepare the end of the supply cord and fit a suitable plug. - Page 16 Important notes Cleaning the PC Cleaning the keyboard and the mouse Use disinfectant wipes to clean the keyboard and the mouse. Remove the retaining ring on the underside of the mouse and then clean the mouse mechanism and the rotating ball. Using both thumbs exert downward pressure on the notches of the retaining ring and turn the Ê...
-
Page 17: Preparation For Use And Operation
Preparation for use and operation Please pay attention to the safety information provided in the chapter "Important notes" and in the manual "Safety, Guarantee and Ergonomics". Unpacking and checking the delivery It is recommended not to throw away the original packaging material! It may be required for reshipment at some later date. -
Page 18: Connecting Devices
Preparation for use and operation Connecting devices Connecting devices The power plug must be disconnected! Do not connect or disconnect cables during a thunderstorm (electric shock). Always take hold of the actual plug body. Do not pull the cable (you could damage the plug or socket)! Read the documentation on the external device before connecting it. -
Page 19: Ports For External Devices
Connecting devices Preparation for use and operation Ports for external devices The ports for external devices are on the rear of the system unit. The ports available on your device depend on the configuration level you have selected. The standard ports are marked with symbols like those below or similar symbols. -
Page 20: Connecting The Keyboard
Preparation for use and operation Connecting devices Connecting the keyboard Use only the keyboard cable supplied. Plug the round plug of the keyboard cable Ê into the keyboard port on the system unit. Plug the other connector of the keyboard Ê... -
Page 21: Connecting The Monitor To The Line Voltage
Connecting the PC to the line voltage Preparation for use and operation Connecting the monitor to the line voltage Prepare the monitor as described in the Operating Manual for the monitor. Ê Plug the data cable of the monitor into the monitor port of the system unit. Ê... -
Page 22: Switching The Pc On And Off
Preparation for use and operation Switching the PC on and off Switching the PC on and off 1 = Power-on indicator 2 = ON/OFF switch System unit is ready-to-operate The power-on indicator (1) glows orange or flashes green/orange. In this mode, you can switch the system unit on with the ON/OFF switch (2). -
Page 23: Switching On The Pc
Switching the PC on and off Preparation for use and operation During installation follow the instructions on the screen. Ê Consult the operating system manual if there is anything unclear about the requested input data. You will find further information about the system, drivers, utilities, updates, and manuals etc. -
Page 24: Indicators On The System Unit
Preparation for use and operation Indicators on the system unit Indicators on the system unit 1 = Floppy disk indicator 3 = Hard disk indicator 2 = Power-on indicator 1 - Floppy disk indicator The indicator lights up when the floppy disk drive of the system unit is accessed. You may only remove the floppy disk when the indicator is dark. -
Page 25: Working With Floppy Disks
Working with floppy disks Preparation for use and operation Working with floppy disks Follow the instructions supplied by the vendor of the floppy disks. Never clean the floppy disk drives with cleaning disks. Even just one attempt would destroy the read/write head in the disk drive within 20 seconds. 1 = Insertion direction 2 = Label area 3 = Write protection tab for a 720 Kbyte or a 1.44 Mbyte floppy disk... -
Page 26: Keyboard
Preparation for use and operation Keyboard Keyboard 1 = Function keys 4 = Cursor control keys 2 = ON/OFF switch (optional) 5 = Numeric keypad (calculator keypad) 3 = Alphanumeric keypad Important keys and key combinations The following description of keys and key combinations refers to MS Windows. Details of other keys and key combinations can be found in the documentation of the relevant application program. -
Page 27: Settings In Bios Setup
Settings in BIOS Setup Preparation for use and operation Euro key enables the output of the euro symbol. Num Lock key by pressing the Num Lock key you switch between the upper- and lower-case levels Lock of the calculator keypad. At upper-case level (Num Lock indicator lit) the digit and comma keys are active. -
Page 28: Bios Setup Security Functions
Preparation for use and operation Property and data protection BIOS Setup security functions The Security menu in BIOS Setup offers you various options for protecting your personal data against unauthorized access, e. g.: • Preventing unauthorized BIOS Setup calls • Preventing unauthorized system access •... -
Page 29: Troubleshooting And Tips
Troubleshooting and tips Take note of the safety notes in the manual "Safety, Guarantee and Ergonomics" and in the chapter "Preparation for use and operation", when you connect or disconnect cables. If a fault occurs, try to correct it as described: •... -
Page 30: The Screen Stays Blank
Troubleshooting and tips The screen stays blank The screen stays blank If your screen remains blank this may have the following causes: Monitor is switched off Switch your monitor on. Ê The PC starts While the PC boots, the screen remains dark for up to a minute depending on the system configuration. -
Page 31: No Mouse Pointer Displayed On The Screen
No mouse pointer displayed on the screen Troubleshooting and tips Wrong monitor has been set under Windows 2000 Restart the PC. Ê If the message Starting Windows appears, press function key Ê [ F 8 ] The Windows 2000 Advanced Options Menu appears. Select Safe Mode of Safe Mode with Network. -
Page 32: Time And/Or Date Is Not Correct
Troubleshooting and tips Time and/or date is not correct Time and/or date is not correct Set the time and/or date. You can set the time and date in the BIOS Setup or in the operating Ê system. If the time and date are repeatedly wrong when you switch on your PC, the battery is flat. Change the lithium battery as described in the Chapter "System expansions". -
Page 33: Tips
Tips Troubleshooting and tips Tips The PC cannot be switched off with the ON/OFF switch Cause: The PC has not been switched on with the ON/OFF switch. Press the ON/OFF switch again. Ê Cause: System crash Press the ON/OFF switch for at least four seconds, until the device switches off. Ê... -
Page 35: System Expansions
System expansions It may be necessary to update the BIOS when carrying out a system expansion or hardware upgrade. In this instance, please contact our customer service center. When installing components with a high power loss, make sure that the maximum permissible temperatures of the individual components are not exceeded. -
Page 36: Opening The System Unit
System expansions Opening the system unit Opening the system unit Switch the PC off. Ê Pull the power plug out of the power outlet so that the system is totally removed from the line voltage! If any cables attached to the system unit are obstructing you, pull out the connectors on the Ê... -
Page 37: Assembling The System Unit
Assembling the system unit System expansions Push the top cover approx. 5 cm in the direction of the arrow (1) and remove it upward (2). Ê Assembling the system unit Place the top cover on the system unit from above so that the guides on the inside of the top Ê... - Page 38 System expansions Assembling the system unit If you have removed three screws when opening the system unit, secure the top cover again Ê with three screws on the front. Replace the front panel. Ê Return the system unit to its original position. Ê...
-
Page 39: Installing A Board
Installing a board System expansions Installing a board The number, position and arrangement of the board slots on system board can be found in the technical manual for the system board. Boards may be installed when the device is shipped. If you want to install an audio card, you may have to switch off an existing onboard audio controller in the BIOS Setup. - Page 40 System expansions Installing a board Removing a board Open the system unit (see "Opening the system unit"). Ê Remove the lines connected to the board. Ê Remove the screw (1). Ê Remove the board from the system unit (2). Ê Place the board into an appropriate packaging.
-
Page 41: Installing And Removing Drives
Installing and removing drives System expansions Installing and removing drives The system unit houses a total of four accessible drives (two 5 1/4-inch drives and two 3 1/2-inch drives) and one non-accessible half-height (Slimline) drive. IDE drives By default four IDE drives are supported. Ideally hard disks are connected to IDE port 1, and accessible drives, for example CD-ROMs, to IDE port 2 (see also the Technical Manual for the system board). - Page 42 System expansions Installing and removing drives Fasten the guide rails with the four screws on the drive. Ê Make the required settings on the drive (if necessary, on installed drives as well). Ê If the drive is the first 5 1/4" drive in your system, then use the upper bay, and use the lower Ê...
-
Page 43: Removing An Accessible 5 1/4-Inch Drive
Installing and removing drives System expansions Removing an accessible 5 1/4-inch drive Open the system unit (see "Opening the system unit"). Ê Pull the data and the power supply connectors from the desired drive. Ê Press sideways on the two springs that secure the drive in the drive cage. Ê... -
Page 44: Changing The Floppy Disk Drive
System expansions Installing and removing drives Changing the floppy disk drive Open the system unit (see "Opening the system unit"). Ê Pull the data and the power supply connectors from the floppy disk drive (1). Ê Press on the spring (2) that hold the bracket in place at the top and pull out the bracket (3). Ê... -
Page 45: Installing A Second 3 1/2-Inch Drive
Installing and removing drives System expansions Push the carrier (1) into the system unit until it snaps into place. Ê Plug the data and the power supply connectors into the floppy disk drive (2). Make sure the Ê polarity is correct. Close the system unit (see "Assembling the system unit"). - Page 46 System expansions Installing and removing drives Remove the protection shield (4). Ê Do not throw away the covers. For cooling, protection against fire and in order to comply with EMC regulations, you must refit the covers if you remove the drive again later. A = Position of screw for non-accessible drive B = Position of screw for accessible drive Take the new drive out of its packaging.
-
Page 47: Replacing A Hard Disk Drive
Installing and removing drives System expansions Replacing a hard disk drive Open the system unit (see "Opening the system unit"). Ê Removing the hard disk Pull the data and the power supply connectors from the hard disk drive. Ê Carefully tilt the system unit so that you have access to the screws on the underside of the Ê... -
Page 48: Extensions On The System Board
System expansions Extensions on the system board Fasten the drive with the four screws. Ê Insert the connectors for the power supply cable and data cable. Ê Close the system unit (see "Assembling the system unit"). Ê If necessary, you must adapt the entry for the drive in the Setup menu. Extensions on the system board Details of how and if you can upgrade the main memory or the processor of your PC are provided in the Technical Manual for the system board. -
Page 49: Technical Data
Noise emission: Sound power level (L ) < 55 dB (A) *) These values only apply for a SCENIC eD with the configuration below. When additional or other components are incorporated, the power consumption or the sound emission (L ) in energy saving mode may exceed the requirements for the environment symbol ("Blue Angel") -
Page 51: Index
Index Connecting cables 10 devices 10 3 1/2-inch drive 16 keyboard 12 monitor 13 mouse 12 Accessible drive parallel port 12 installing 33 power voltage 13 removing 35 serial port 12 Accumulator, disposal 4 Connecting to power voltage 13 Activating, security measures 19 Contents of delivery 9 Alphanumeric keypad 18 Control key 19... - Page 52 Index Expansion 27 External devices LAN port 11 connecting 10 Lead-sealing 20 ports 11 Line in 11 Line out 11 Lithium battery 40 replacing 40 FCC statement 5 First time, switching on 14 Flashing power-on indicator 16 Floppy disk Main memory 40 cannot be read or written 23 Manuals, further 25 Floppy disk drive...
- Page 53 Index Select, power cord 5 cabling 10 Serial port 11 cannot boot 21 connecting devices 12 cleaning 7 Setting connecting 10 rated voltage 13 connecting to power voltage 13 Settings opening 27 BIOS Setup 19 ports 11 Setup, see BIOS Setup setting up 9 Shift key 18 switching off 15...
