9 RECOMMENDED SPARE PARTS FOR
INVERTER
Part number
C16507
C16505
C16520
C29523
C29522
C29508
C12442
C12358
C12359
C12407
C12403
C12777
ADEZP0AE - AC-2 INVERTER - User Manual
Description
Protected 500 A strip Fuse.
Protected 355 A strip Fuse.
6.3 A 20 mm Control Circuit Fuse
SW 180 80 V
Single Pole Contactor
SW 180 48 V
Single Pole Contactor
SW 180 24 V
Single Pole Contactor
Molex Minifit Connector 2 pins Female
Molex Minifit Connector 4 pins Female
Molex Minifit Connector 6 pins Female
Molex Minifit Connector 12 pins Female
Molex Minifit Connector 14 pins Female
Female Molex Minifit pin harness side
