Pump - Zapi AC-2 User Manual

AUX STOP
OUTPUT ON
RAMP
BRAKE ON
BRAKE OFF
HYDRO
CONT. ON
HYDRO OFF
CONT.
EXCL. ON
HYDRO
EXCL. OFF
HYDRO

5.4.2 Pump

Using the config menu of the programming console, the user can configure the
following functions.
SUBMENU "SET OPTIONS"
1) HOUR COUNTER
-
-
2) BATTERY CHECK
-
ADEZP0AE - AC-2 INVERTER - User Manual
F9
OUTPUT
-It drives the coil of a
electromagnetic brake.
-The hydraulic steering function
request is sent to the pump
inverter by the can-bus link.
-It drives the coil of a
electromagnetic brake.
-The hydraulic steering function
request is sent to the pump
inverter by the can-bus link.
-It drives the coil of a hydraulic
steering contactor.
-The hydraulic steering function
request is also sent to the pump
inverter by the can-bus link.
-It drives the coil of a hydraulic
steering contactor.
-The hydraulic steering function
request is also sent to the pump
inverter by the can-bus link.
-It drives the coil of a hydraulic
steering contactor.
-The hydraulic steering function
request is also sent to the pump
inverter by the can-bus link.
-It drives the coil of a hydraulic
steering contactor.
-The hydraulic steering function
request is also sent to the pump
inverter by the can-bus link.
RUNNING: the counter registers travel time only.
KEY ON: the counter registers when the "key" switch is closed.
ON: the battery discharge level check is carried out; when the battery
level reaches 10%, an alarm is signalled and the maximum current is
reduced to the half of the programmed value.
BEHAVIOUR ON A SLOPE
The truck is electrically hold on a
slope; when the time set by
""auxiliary time"" parameter is
elapsed the brake is applied and
the 3-phase bridge is released.
Do not use this combination if
the negative brake is not
installed.
The truck is not electrically hold
on a slope, but comes down
very slowly; when the time set
by ""auxiliary time"" parameter is
elapsed, the brake is applied
and the 3-phase bridge is
opened. Do not use this
combination if the negative
brake is not installed.
The truck is electrically hold on a
slope; when the time set by
""auxiliary time"" parameter is
elapsed, the truck comes down
very slowly, till the flat is
reached.
The truck is not electrically hold
on a slope, but comes down
very slowly till the flat is
reached.
The truck is electrically hold on a
slope; when the time set by
""auxiliary time"" parameter is
elapsed, the truck comes down
very slowly, till the flat is
reached.
The truck is not electrically hold
on a slope, but comes down
very slowly till the flat is
reached.
Page - 31/64
