Summary of Contents for Bodyworx A805
-
Page 2: Safety Instructions
Safety Instructions • To ensure the best safety of the exerciser, regularly check it for and advice with respect to the individual intensity of stress for damage and worn parts. your work-out and sensible eating habits. • Be sure to set up the exerciser in a dry and even place and •... -
Page 3: Exploded Drawing
Exploded drawing: 38 19 36 52 21 27 24 53 2 66 54 62 65... -
Page 4: Checking List
Checking list: 46L&46R 41L&41R D22*D8.5*1.5T D15.4*D8.2*2T M8*1.25*90L M8*1.25*20L M8*15L... -
Page 5: Part List
Part list: Part No. Description Q’ty Part No. Description Q’ty Main frame Flat washer D22*D10*2T Rear stabilizer Upper computer cable 1000L Adjustable foot cap Lower computer cable 600L Front stabilizer Left computer bracket Left foot cap Right computer bracket Right foot cap Cover 80.6*56*52.5 Domed nut M8*1.25*15L Flat washer D16*D8.5*1.2T... -
Page 6: Assembly Drawing
Assembly drawing: Step 1 ( x4) M8*90L D15.4 M8*15L 1) Assemble the front stabilizer (4) and the rear stabilizer (2) to the main frame (1) by the bolt (7), the spring washer (51), the curved washer (53) and the domed nut (6). 2) The height of the adjustable foot cap on the rear stabilizer could be adjusted up and down. -
Page 7: Adjustable Seat Tube 1
Step 2 ( x3) 1) Assemble the seat (10) to the adjustable seat tube (11) by the flat washer (12) and the Nylon nut (13) shown as fig. a. 2) Put the seat post (9) into the main frame (1). And adjust the seat post up and down via the round knob (31) shown as fig. -
Page 8: Upper Protective Cover 1
Step 3 ( x4) D15.4 M8*20L 1) Assemble the upper protective cover (28) to the handlebar post (29) shown as fig. a. 2) Connect the upper computer cable (40A) with the lower computer cable (40B) that is pre-assembled to the motor (65) shown as fig. b. 3) Assemble the handlebar post (29) to the main frame (1) by the bolt (20), the spring washer (51) and the curved washer (53). -
Page 9: Handle Pulse 2
Step 4 ( x4) M5*10L 1) Assemble the handle bar (36) to the handle bar post (29) by fixing the cover (42), the flat washer (43), the spring washer (44), the bushing (45) and the T-shaped knob (37). 2) Connecting the upper computer cable (40A) and the handle pulse cable (30) with the computer (38). -
Page 10: Pedal
Step 5 1) Assemble the computer brackets (41L)& (41R) to the handle bar post by fixing the screw (69) and the screw (14). 2) Assemble the waterbottle holder (73) and waterbottle (74) to the handle bar post (29) by fixing the screw(75) 3). -
Page 11: Operation Procedure
Computer Operation Instructions SM-2780-71 BUTTON FUNCTION: In stop mode, the mode is to confirm all exercise data setting, and enter into MODE/ENTER : program. In stop mode, press the button back to main menu. RESET : START/STOP : To start or stop exercise. RECOVERY : To test hear rate recovery status. -
Page 12: User Program
Drawing A Drawing B Drawing C Drawing D 3. In main menu, first exercise program MANUAL will flash, user may press UP and DOWN button to select MANUAL PROGRAM (12 profiles) (drawing E) PROGRAM USER PROGRAM HRC WATT. Drawing E Drawing F 4. - Page 13 8. WATT : The preset watt value 120 is flashing on screen in WATT setting mode. User may use UP, DOWN button to set target value from 10 to 350. Press MODE button for confirm. Brick area display total 8 rolls and every profile are composing of 20 rolls. While exercise, profile display shall rolling for every rolls until user finish exercise for it selected profile.
