CONTROL COMMAND
IC-R20
69
CI-V connection example
to [SP/CI-V]
3.5(d) mm stereo plug
must be used.
GND
3.5(d) mm
I/O
Power supply
Optional
9–15VDC
BC-25
RS-232C
cable
CT-17
GND
I/O
Computer
