6.6 RS-232 Protocols

Pin Assignment
CMSI-8H8CVE
PIN
1
2
3
4
5
6
7
8
9
Baud Rate: 19200 bps
Data bit: 8 bits
Parity: None
Stop Bit: 1
Flow Control: None
7
Assignment
NC
Tx
Rx
NC
GND
NC
NC
NC
NC
Remote Control Console
PIN Assignment
1 NC
2 Rx
3 Tx
4 NC
5 GND
6 NC
7 NC
8 NC
9 NC
