- Page 1 Commercial BODY WORX BODY WORX Magnetic Spin Bike Owner’s Manual Model No: AM900 Retain this owner’s manual for future reference Read and follow all instructions in this owner’s manual Version A...
- Page 2 AM900 - INSTRUCTIONS FOR USE The model AM900 is designed to be used as a “spin” cycle in fitness studios and health clubs. It has a fixed wheel driven flywheel and should only be used under professional supervision. Installation - it is important that the AM900 is correctly assembled and we recommend that installation and assembly be carried out by suitably qualified personnel.
- Page 3 AM900 - Assembly Diagrams...
-
Page 4: Step 1 (Front Foot)
AM900 - Assembly Step 1 (Front Foot) Attach the front foot (6) to the frame using the bolt (3), washer (4) and nut (5). Step 2 (Rear Foot) Attach the front foot (2) to the frame using the bolt (3), washer (4) and nut (5). -
Page 5: Step 4 (Handlebar & Stem)
Step 4 (Handlebar & Stem) Attach handlebar (11) onto handle bar stem (14), assembly down plate (25), washer (12a) bolt (26) and lock lever (12), slide the handlebar (11) until reach your required position. Using lock lever for tightening. And then put the handlebar-stem set onto front tube, adjust to your ideal position., and then using lock lever (18) to tighten. -
Page 6: Step 6.7. (Bottle Cage)
Step 6.7. (Bottle Cage) Attach screw (10) into bottle cage (9) on front fork in required position using a 4mm allen key STEP 6 STEP 7... - Page 7 AM900 Diagrams...
- Page 8 M900 Parts List PARTS NO DESCRIPTION PARTS NO DESCRIPTION 1 Main Frame 43 Plastic Brake Bass 2 Rear Ground Tube 44 Bolt M8 x P1.25 x 20L 3 Ground Tube Fixed Bolt 45 Sleeve 8mm x 11mm x 12L 4 Washer 46 Nut M8 x P1.25 5 Nut 47 Screw M5 x P0.8 x 6L...
- Page 9 BODY WORX BODY WORX...
