Summary of Contents for Bodyworx AENERGISER
- Page 1 Magnetic Bike BODY WORX BODY WORX Model No: AENERGISER Retain this owner’s manual for future reference Read and follow all instructions in this owner’s manual Version A...
-
Page 2: Explode Drawing
EXPLODE DRAWING -02-... - Page 3 PARTS LIST AND TOOLS -03-...
-
Page 4: Assembly Instruction
ASSEMBLY INSTRUCTION STEP 1 1. Prepare a clean area. Take the main frame bike with all parts out of the carton and put them on such area. Check the parts with the parts list to make sure there’s no missing part in the carton. - Page 5 ASSEMBLY INSTRUCTION STEP 3 1. Assemble the base tube (34) to the main frame with 5 screws (36) and 1 flat washer (25) and 4 wave washers (35). STEP 4 1. Assemble the straps onto the pedals as the sketches. Adjust the ideal length of the straps according to your size of feet.
- Page 6 ASSEMBLY INSTRUCTION STEP 5 1. Release 4 Allen bolts (36) and wave washers (35) which are pre-assembled on the main frame (37). 2. Install the handlebar post (01) onto the main frame (37). Turn the Tension Control Knob back and forward to make sure it is smoothly moving.
- Page 7 ASSEMBLY INSTRUCTION STEP 6 1. Install the handlebar (03) onto the bracket of the handlebar post (01). Make sure the pulse cable is outside the top of the handlebar post with the computer bracket (plate) protruded on top. 2. Put the metal cover (04) pressing the handlebar.
- Page 8 ASSEMBLY INSTRUCTION STEP 8 1. Slide the computer (13) to bracket. 2. Plug in the cable between the computer and the handelbar post. 3. Plug the cable of hand pulse sensor (02) from handlebar into the computer. -08-...
- Page 9 7380D Computer Instruction Manual Buttons: MODE: Press the button to select functions, and hold this button to total reset all function values Fucntions: RPM SPEED: Display exercise speed. TIME: Record exercise time by counting up or down. DISTANCE: Record exercise distance by counting up or down. CALORIES: Record calories consumption during exercise.
- Page 10 * IMPORTANT SAFETY INFORMATIONS * PLEASE FOLLOW THE SAFETY RULES BELOW TO AVOID INJURY AND/OR ACCIDENTS KEEP THE BIKE AWAY FROM THE ACCESS OF CHIDLREN, DO NOT ALLOW THE CHILDREN TO BE AROUND WHEN USING THE MACHINE. DO NOT RIDE THE BIKE STANDING UP. DO NOT RIDE WHILE WEARING LOOSE ROBES, LOOSE PANTS OR SKIRTS.
-
Page 11: Warm-Up Exercise
WARM-UP EXERCISE -11-... - Page 12 BODYWORX BODY WORX...
