- Page 1 BODYWORX BODYWORX SPIN BIKE Model No. A117BB...
- Page 2 GPI Sports & Fitness Warranty Registration Form Congratulations on purchasing your product, we at GPI believe that our product range is of the highest quality and represents great value for money. We back our product range up with our industry leading warranty. Please see below for the step by step instructions on how to register your product warranty online.
-
Page 3: Table Of Contents
INDEX * SAFETY & MAINTENANCE INSTRUCTIONS ----- PAGE 2 * FEATURES ---------------------------------------------PAGE 3-4 * ASSEMBLY INSTRUCTION Parts List ---------------------------------------------------PAGE 5 Assembly Step A-------------------------------------------PAGE 6 Assembly Step B-------------------------------------------PAGE 6 Assembly Step C ------------------------------------------PAGE 7 Assembly Step D ------------------------------------------PAGE 7 Assembly Step E ------------------------------------------PAGE 8 Assembly Step F ------------------------------------------PAGE 8 * EXPLODED DRAWING --------------------------------PAGE 9 * BILL OF MATERIAL -----------------------------------PAGE 10... -
Page 4: Safety & Maintenance Instructions
SAFETY & MAINTENANCE INSTRUCTIONS 1. Once fully assembled, please check that all hardware parts such as bolts, nuts and washers are positioned and secured firmly. 2. Please check regularly that the safety chain guard that protects the moving parts of the machine is secured and in good order. 3. -
Page 5: Features
F E A T U R E S Emergency Brake Saddle Tension Control Seat Slider Adjustable Knob Seat Post Heavy Flywheel Transportation Wheel Durable Crank Belt Driven... - Page 6 Adjustable Knob Easy to adjust the height of both seat post & handlebar Heavy Flywheel High-inertia flywheel creates the high momentum Transportation Wheel Anyone can move this machine using the 2 wheels Durable Crank Ensure the best durability when in big force Belt Driven Most comfortable and less noisy Seat Post...
-
Page 7: Assembly Instruction
ASSEMBLY INSTRUCTION PARTS LIST Q’TY DESCRIPTION SPECIFICATION Multi-Wrench Chrome & dipping Handlebar Saddle With 2 hex nuts Pedal ( R ) Right Threaded Pedal ( L ) Left Threaded Carriage Bolt M8*50 φ16*φ8.5*1.6 Washer Flange Nut Front Stabilizer with 2 wheels Rear Stabilizer without wheels... -
Page 8: Assembly Step A
Assembly Step A Attach the Rear stabilizer (#57) to the frame using two Carriage Bolts (#51) and two Flange Nuts (#54) and two Washers(#52), and secure firmly using the Multi-Wrench (#15). Assembly Step B Attach the Front stabilizer (#56) to the frame using two Carriage Bolts(#51) and two Flange Nuts (#54) and two Washers(#52), and secure firmly using the Multi-Wrench (#15). -
Page 9: Assembly Step C
Assembly Step C Thread the right pedal (#42R) that has "R" on spindle to the right side arm of the bike using the Multi-Wrench (#15) . Please note that the R pedal is right-hand threaded which must be turned clockwise to tight. Thread the left pedal (#42L) that has "L"... -
Page 10: Assembly Step E
Assembly Step E Attach the Seat ( #28 ) to the Seat slider with two M8 Hex Nuts, and secure firmly using the Multi-Wrench (#15). Make sure that the nose of the Seat is pointing straight ahead before you tighten the Hex Nuts. Note: The M8 Hex Nuts may be pre-attached to the seat clamp. -
Page 11: Exploded Drawing
EXPLODED DRAWING... -
Page 12: Bill Of Material
BILL OF MATERIAL DESCRIPTION DESCRIPTION Q'TY/BIKE Q'TY/BIKE Frame Outer Chain Guard Long Sleeve Belt Adjustable Knob Big Pulley Allen Bolt Bottom Bracket Allen Nut 40-1 Tension Control Crank Bolt 40-2 Square Washer Crank (R ) Helical Compression Spring Crank (L) Square Nut Crank Cap 41-1... - Page 16 BODYWORX BODYWORX Model No: # A117BB To register your warranty, please go to www.gpisports.com.au...
