Photometric Data - ETC Source Four Revolution User Manual

Photometric Data

M i n i m u m S p r e a d
Throw Distance (d)
37.2ft
11.3m
1/10 Peak Diameter
10ft
3.0m
FC 272
LUX 2930
1/10 Peak
Degree Candlepower
Lumens
15˚ 376,520 10,830
M e d i a n S p r e a d
Throw Distance (d)
22.3ft
6.8m
17.2˚
1/10 Peak Diameter
10ft
3.0m
FC 309
LUX 3325
1/10 Peak
Degree Candlepower
Lumens
25˚ 153,730 11,760
M a x i m u m S p r e a d
Throw Distance (d)
16.2ft
4.9m
23.7˚
1/10 Peak Diameter
10ft
3.0m
FC 299
LUX 3220
1/10 Peak
Degree Candlepower
Lumens
35˚ 78,410 10,950
All photometric data in this document was prepared using standard production fixtures, and the Prometric™ CCD measurement system.
Fixtures were adjusted for blending (cosine) distribution, and were tested with a calibrated lamp at its rated voltage. All data were normalized to nominal lamp lumens.
To determine illumination in footcandles or lux at any throw distance, divide candlepower by distance squared.
* (distance from origin) = (throw distance) x (throw distance multiplier)
44.7ft 52.1ft 59.6ft
13.6m 15.9m 18.2m
15.3˚
10.5˚
1/2 Peak 1/10 Peak
12ft 14ft 16ft
3.7m 4.3m 4.9m
188 139 106
2025 1495 1140
1/2 Peak 1/10 Peak
Efficiency
Lumens
7,060 47.19%
26.7ft 31.2ft 35.6ft
8.1m 9.5m 10.9m
25.3˚
1/2 Peak 1/10 Peak
12ft 14ft 16ft
3.7m 4.3m 4.9m
216 158 121
2325 1700 1300
1/10 Peak
1/2 Peak
Lumens Efficiency
7,425 51.24%
19.4ft 22.7ft 25.9ft
5.9m 6.9m 7.9m
34.3˚
1/2 Peak
1/10 Peak
12ft 14ft 16ft
3.7m 4.3m 4.9m
208 152 117
2240 1640 1260
1/10 Peak
1/2 Peak
Lumens Efficiency
6,925 47.71%
Throw Distance Multiplier*
LPW
14.4
Throw Distance Multiplier*
LPW
15.7
Throw Distance Multiplier*
LPW
14.6
3%
10%
50%
10˚ 8˚ 6˚ 4˚ 2˚ 0º 2˚
Degrees
3%
10%
50%
15˚ 12˚ 9˚ 6˚ 3˚ 0˚ 3˚
Degrees
3%
10%
50%
20˚ 16˚ 12˚ 8˚ 4˚ 0˚ 4˚
Degrees
400K
300K
200K
100K
0
4˚ 6˚ 8˚ 10˚
X
Y
200K
150K
100K
50K
0
6˚ 9˚ 12˚ 15˚
X
Y
100K
75K
50K
25K
0
8˚ 12˚ 16˚ 20˚
X
Y
