S a f e t y C a b l e
The safety cable (or other approved safety device) should be secured to one of the handles
on the upper enclosure, wrapped around the hanging structure (pipe), then secured to the
other handle on the upper enclosure. Take care to leave as little slack as possible in the
safety cable to avoid the cable catching the yoke of the fixture.
F i x t u r e W e i g h t
Total weight depends on how the individual fixture is configured. Use the table below to
calculate the total weight of your fixture.
Base Fixture
Blank Module
Iris Module
Overview
Device
74 lb
1.8 lb
3 lb
Weight
33.6 kg Static Wheel Module
Rotating Wheel
0.7 kg
Module
1.4 kg Shutter Module
Device
3 lb
3.7 lb
10.4 lb
Weight
1.4 kg
1.7 kg
4.7 kg
