Configuration

With Source Four Revolution, you decide how to configure your light. The standard base
unit provides pan, tilt, beam-edge change, 15-35° zoom range, two Blank Modules, Internal
Media Frame, integrated color scrolling, and on-board dimming. The unit's module bays
can be filled with any of the modules described below.
B l a n k M o d u l e ( B M )
• Space for one static metal M-sized gobo
I r i s M o d u l e ( I M )
• 18-leaf iris
• Smooth operation
• Simple, repeatable beam-size control
• On-board auto-sensing electronics
S h u t t e r M o d u l e ( S M )
• Multi-plane shutters for flexible beam shaping
• All shutters have +/– 45° rotation (total range of motion = 90°)
• On-board auto-sensing electronics
S t a t i c W h e e l M o d u l e ( S W M )
• Four positions, typically setup as three positions plus open
• Gobos or dichroic color filters
• Uses M-sized gobos, glass or metal
• On-board auto-sensing electronics
R o t a t i n g W h e e l M o d u l e ( R W M )
• Three positions, plus open
• Rotating, indexable gobos
• Uses M-sized gobos, glass or metal
• On-board auto-sensing electronics
M o d u l e / B a y C o m p a t i b i l i t y
Blank Module (BM)
Iris Module (IM)
Shutter Module (SM)
Static Wheel Module (SWM)
Rotating Wheel Module (RWM)
Configuration
Module Type
a) Prolonged use of the Rotating Wheel Module in the Rear Bay may cause the belt within the module
to degrade. To ensure peak performance of the RWM, use it in the Front Bay.
Front Bay
Yes
Yes
No
Yes
Recommended for
best performance
Rear Bay
Yes
Yes
Yes
Yes
Not
a
Recommended
