Step 6:
Step 7:
Static Wheel
Alignment Hole
Static Wheel
Frame
22
Insert the spring into the frame. Ensure that the gobo/filter is held securely in
place and that the spring is fully inserted in the frame.
Reinsert the module into the fixture and tighten the screws securing the module.
Rotating Wheel
Alignment Hole
DETAIL: gobo installed
Spring
M-Size Gobo
Source Four Revolution User Manual
