NTI XTENDEX USB AND VGA VIDEO EXTENDER

MATERIALS

Materials Included with this kit:
NTI XTENDEX Local and Remote Unit
1 or 2- 100VAC to 240VAC at 50 or 60Hz-5VDC/3.0A AC Adapter (see chart on page 1)
1-USB2-AB-1M-5T 1 Meter USB Type A Male-USB Type B Male cable
1-VEXT-3 15HD Male-to-15HD Female 3 foot cable (Qty 2 in models with dual video support only)
2- SA-3-MM 3.5MM male-to-male audio cables (models with audio support only)
1- DB9M-RJ45F Serial Adapter RJ45 Female-DB9 Male (models with RS232 support only)
1- DB9F-RJ45F Serial Adapter RJ45 Female-DB9 Female (models with RS232 support only)
2- 3 foot RJ45-to-RJ45 CAT5 Patch Cables (models with RS232 support only)
CD containing a pdf of this manual
Materials Not supplied but REQUIRED:
CAT5/5e/6/7 unshielded twisted-pair cable(s) terminated with RJ45 connectors wired straight thru- pin 1 to pin 1, etc. (see
page 10 for proper EIA/TIA 568 B wiring method and resolution/distance chart)
Cables can be purchased from Network Technologies Inc by calling (800) 742-8324 (800-RGB-TECH) in the US and Canada or
(330) 562-7070 (worldwide).
