NTI XTENDEX USB EXTENDER

INTRODUCTION

The USB Extender extends four USB devices up to 200 feet. Each USB extender consists of a local unit that connects to a
computer and a remote unit that connects to four USB devices.
•
Supports fully transparent USB connections – able to support all common hardware platforms including PC, SUN and
MAC and their associated peripherals.
•
Extend devices such as keyboards, mice, printers, game controllers, USB flash drives, touch screen monitors,
whiteboards, etc.
•
Compliant with USB 1.1 specifications.
•
Supports low speed and full speed USB devices
•
Supports Plug-n-Play specification

MATERIALS

Materials Included with this kit:
NTI XTENDEX Local and Remote Unit
1-100VAC to 240VAC at 50 or 60Hz-5VDC/3.0A AC Adapter
1-USB2-AB-1M-5T USB Type A Male-to-USB Type B Male 1 meter cable
Mounting bracket kit (2-MP4869 Universal Extender Brackets, 4- #4-40x3/16" Mach. Screws)
2- 3/16" x 1" Wall Anchors and #6x3/4" Phillips Screws
CD with this manual
Materials Not supplied but REQUIRED:
CAT5e Solid/Stranded UTP/STP; CAT6 Solid or Stranded UTP/STP ; CAT6a Solid UTP; CAT7 Solid STP cable(s) terminated
with RJ45 connectors wired straight thru- pin 1 to pin 1, etc. (see page 6 for proper EIA/TIA 568 B wiring method)
Cables can be purchased from Network Technologies Inc by calling (800) 742-8324 (800-RGB-TECH) in the US and Canada or
(330) 562-7070 (worldwide).
