INTRODUCTION

The USB Extender with VGA Video extends four USB devices and a VGA monitor up to 200 feet. Each USB extender consists of
a local unit that connects to a computer and also supplies video to a local monitor, and a remote unit that connects to four USB
devices and a monitor.
•
Supports fully transparent USB connections – able to support all common hardware platforms including PC, SUN and
MAC and their associated peripherals.
•
Extend devices such as keyboards, mice, printers, game controllers, USB flash drives, touch screen monitors,
whiteboards, etc.
•
Supports local and remote VGA monitors.
•
Supports resolutions to 2048x1536 (see Resolution/Distance Chart on page 10).
•
DDC2B support for local or remote monitor.
•
Compliant with USB 1.1 specifications.
•
Supports low speed and full speed USB devices
•
Supports Plug-n-Play specification
•
Video quality adjustment for different lengths of CAT5/5e/6/7 cable is done manually
•
Optional dual video and dual video + two-way audio support (speakers and microphone)+RS232 support
Models Available:
Model VGA Monitor
Support
ST-C5USBVT
ST-C5USB2VT
ST-C5USB2V2ARST
2-Way Audio and
RS232 Support
Yes No
Dual Video No
Dual Video Yes
Power Supply
1 (Remote Only)
2
2
1
