Assembly Instructions - Procom FBD28TCC-M-HC User Manual

1. Insert Cam Locks (BB) into Panel (B). Screw Cam Dowels (AA) into
the Left Side Panel (C) and the Right Side Panel (D). Attach Panel
(B) into assembled frame (C, D) by tightening the Cam Locks (BB)
as shown in Figure 1.
Hardware Used
4) Cam Dowel
AA
4) Cam Lock
BB
AA
BB
D
2. Insert Cam Locks (BB) into the Left Side Panel (C) and the Right
Side Panel (D). Screw Cam Dowels (AA) into Base (E). Attach
Base (E) into assembled frame by tightening the Cam Locks (BB)
as shown in Figure 2.
Hardware Used
6) Cam Dowel
AA
6) Cam Lock
BB
D
4

ASSEMBLY INSTRUCTIONS

B
Figure 1
BB
AA
Figure 2
3. Fasten the wood support brackets attached to the Left Side (C)
and Right Side (D) Panels with ST4Screw 1
(E) as shown in Figure 3.
II
C
D
For Corner Mantel, skip to step 8, page 7.
4. Insert Cam Locks (BB) into assembled framel (B,C,D). Screw Cam
Dowels (AA) into Top (A). Attach Top (A) into assembled frame by
tightening the Cam Locks (BB) as shown in Figure 4.
6) Cam Dowel
AA
6) Cam Lock
BB
C
E
www.usaprocom.com
Hardware Used
4) ST4 Screw 1 / "
9
16
II
Figure 3
Hardware Used
A
AA
B
BB
D
Figure 4
/ " (II) to the Base
9
16
C
E
C
200087-01A
