5. Fasten the wooden support brackets attached to the top of the
mantel assembly to the Top (A) with ST4 Screw 1
in Figure 5.
Hardware Used
II
4) ST4 Screw 1
II
200087-01A
ASSEMBLY INSTRUCTIONS
/ " (II) as shown
9
16
/ "
9
16
A
Figure 5
6. After assembling the mantel, lift to the upright position. Carefully,
push the fireplace insert from the front of the mantel as shown in
Figure 6.
7. Position the fireplace to the desired location as shown in Figure 7.
www.usaprocom.com
Fireplace Insert
Figure 6
Wall
Figure 7
5
