2.3 Printer Parts

2.3.1 Front View

Top Cover
Label Opening
Backing Paper Opening

2.3.2 Rear View

6

3 Setup

3.1 Setting Up the Printer

1. Place the printer on a flat, secure surface.
2. Make sure the power switch is off.
Fig.1 Top Front View
1 2 3 4
5
Fig.2 Rear View
Clear Window
LED Indicator
Feed Button
Top Cover Open Lever
Front Panel
1. USB Interface
2. Centronics Interface
3. RS-232C DB-9 Interface
4. Power Jack
5. Power Switch
6. Rear Label Guide
3
