Front Panel; Edsp Software - K-array KA10-10 User Manual

9. FRONT PANEL

1. Protection indicator
2. Indicator of proper operating
3. Indicator of signal/clip CH1 IN
4. Indicator of signal/clip CH2 IN
5. Power switch

10. eDSP SOFTWARE

The amplifier is equipped with two INPUTS
and four DSP OUTPUTS that work using
K-array eDSP software.
This software runs on all Windows PCs,
it communicates via USB or RS485
(K-USB).
The eDSP software allows you to manage
EQ, Dynamics and signal levels in real
time.
The amplifier out of the box has no on
board preset loaded. It's necessary to
connect it via USB the first it is used, and
upload the right preset for your application.
16
1 2 3 4 5 6
SYSTEM REQUIRED
Operating systems:
Win XP/ Vista / 7.
Minimum requirements:
CPU
RAM
Recommended requirements:
RAM
ENGLISH
5
KA7
300 MHz
128 Mb
512 Mb
