11. RACK ADAPTER

DEVICE A
S1
22
spacers
S2
S1
S2
SINGLE RACK
DOUBLE RACK
DEVICE B
on DEVICE B as in the
diagram on the left. Then
fixing all four screws on
DEVICE B and the two
screws through S1 on the
Attach the two devices using
the last two screws and fix the
ENGLISH
Fix the two rack
adapters using the
supplied screws
as shown in the
drawing.
Unscrew the 4
anchor points of
the front panels
and remove
them.
Remove the
smaller steel
spacer (S2)from
DEVICE A
and adjust S1
refit the front panels
DEVICE A .
rack adapters.
