WARNING: FOLLOW THE INFORMATION IN
THESE INSTRUCTIONS EXACTLY, IF NOT, A FIRE
OR EXPLOSION MAY RESULT CAUSING
PROPERTY DAMAGE, PERSONAL INJURY OR
LOSS OF LIFE.
WARNING: DO NOT STORE OR USE GASOLINE
OR ANY OTHER FLAMMABLE VAPORS AND
LIQUIDS NEAR THIS OR ANY OTHER GAS
APPLIANCE.
WHAT TO DO IF YOU SMELL GAS:
Do not try to light any appliance.
Do not touch electrical switches; do not use the phone
in your building.
Immediately call your gas supplier from a phone
outside the structure. Follow your gas supplier's
instructions.
If you cannot reach your gas supplier, call the fire
department or 911.
A qualified installer, service agency, or gas supplier must
perform installation and service of this appliance. In the
Commonwealth of Massachusetts, all installation of gas
lines and gas fittings must be performed by a licensed gas
fitter or licensed plumber.
Bristol DX
GAS-FIRED DIRECT-VENT HEATER
Owner's Manual
Installation & Operating
Read This Manual in Its Entirety
Operate And Maintain This Gas Heater
According To This Instruction Manual.
SAVE THESE INSTRUCTIONS!
AVERTISSEMENT:
ASSUREZ-VOUS
SUIVRE
LES
INSTRUCTIONS
CETTE NOTICE POUR RÉDUIRE AU MINIMUM LE
RISQUE D'INCENDIE OU POUR ÉVITER TOUT
DOMMAGE MATÉERIEL, TOUTE BLESSURE OU
LA MORT.
AVERTISSEMENT: NE PAS ENTRESPOSER NI
UTILISER D'ESSENCE NI D'AUTRE VAPERURS
OU
LIQUIDES
INFLAMMABLES
VOISINAGE DE CET APPRAREIL OU DE TOUT
AUTRE APPAREIL.
QUE FAIRE SI VOUS SENTEZ UNE ODEUR DE GAZ:
Ne pas tenter d'allumer d'appareil.
Ne touchez à aucun interrupteur. Ne pas vous servir
des téléphones se trouvant dans le batiment où vous
vous trouvez.
Appelez immédiatement votre fournisseur de gaz
depuis un voisin. Suivez les instructions du
fournisseur.
Si vous ne pouvez rejoindre le fournisseur de gaz,
appelez le service dos incendies.
L'installation et service doit être exécuté par un qualifié
installer, agence de service ou le fournisseur de gaz.
Hearthstone Quality Home Heating Products, Inc. ®
(Model 8762)
Instructions
DE
BIEN
DONNÉ
DANS
DANS
LE
Bristol DX Model 8762
Manual: 6400-40466
R: 3/26/2013

Advertisement

loading

  Also See for HearthStone Bristol DX

  Related Manuals for HearthStone Bristol DX

  Summary of Contents for HearthStone Bristol DX

  • Page 1 L’installation et service doit être exécuté par un qualifié fitter or licensed plumber. installer, agence de service ou le fournisseur de gaz. Hearthstone Quality Home Heating Products, Inc. ® Bristol DX Model 8762 Manual: 6400-40466 R: 3/26/2013...
  • Page 2 Intentionally Blank...
  • Page 3: Information Sheet

    Address: Phone: E-mail Website: Gas Supplier: Address: Phone: E-mail Website: Read this Owner’s Manual before installing, or operating your BRISTOL DX. Retain this manual for future reference. SERVICE RECORD Date Who Performed Work Work Performed Notes: WHAT WHEN Firebox Cleaning.....
  • Page 4: Table Of Contents

    ..............................6 AFETY NFORMATION & F ........................ 8 ROFLAME ONTROL YSTEM EATURES Bristol DX 8762 Model Overview ..........................8 Control Functions ..............................10 ............................... 12 PECIFICATIONS ............................ 13 NSTALLATION REPARATION Codes ..................................13 Items Required for Installation ..........................13 Packing List ................................13 Unpacking and Inspection ............................
  • Page 5: Introduction

    Hearthstone Quality Home Heating Products, Inc. Bristol DX Model 8762 Introduction Congratulations on your purchase of the Bristol DX b. Split Burner control via remote Model 8762, Gas-Fired Direct-Vent heater. The c. Six (6) blower speeds, adjustable via the Bristol, by Hearthstone, incorporates the latest in...
  • Page 6: Safety Information

    Hearthstone Quality Home Heating Products, Inc. Bristol DX Model 8762 Safety Information Your Bristol is an attractive and extremely efficient Service Caution and easy to use heater, utilizing today’s best If you believe your Bristol is not in any way technologies.
  • Page 7 Hearthstone Quality Home Heating Products, Inc. Bristol DX Model 8762 (S’ASSURER BRÛLEUR Ceramic Logs, & Burner COMPARTIMENT COMMANDES SONT If the decorative ceramic log, or burner material PROPRES. VOIR INSTRUCTIONS supplied with the Bristol is damaged or parts are D’INSTALLATION D’UTILISATION...
  • Page 8: Proflame Control System & Features

    Proflame 2 Control System & Features NOTE: OPEN DOOR UNDER THE ASH LIP AND DROP DOWN THE MODESTY PANEL FOR ACCESS TO ELECTRICAL AND GAS CONNECTIONS. Bristol DX 8762 Model Overview Proflame 2 GTMFS System The Proflame 2 GTMFS is a modular remote control system that directs the functions of the Bristol.
  • Page 9 Hearthstone Quality Home Heating Products, Inc. Bristol DX Model 8762 is available or by the batteries in the Back-up Battery step down the flame height. The reverse happens Holder during a power outage. when the room cools - the valve will automatically gradually increase the flame height.
  • Page 10: Hearthstone Quality Home Heating Products, Inc. Bristol Dx Model

    Hearthstone Quality Home Heating Products, Inc. Bristol DX Model 8762 Control Functions Pilot Mode Continuous Pilot (CPI): Running the Bristol 8762 in CPI mode will keep your pilot on even when the thermostat does not call for heat and when the burner is not lit. This is an advantage in cold climates or under windy conditions.
  • Page 11 Hearthstone Quality Home Heating Products, Inc. Bristol DX Model 8762 Remote Transmitter Figure 6 - Remote Transmitter Function Keys (remote color may differ from shown) ON/OFF Key: Controls the insert. Mode Key: Toggles through the component to be controlled (split flow burner, blower or auxiliary...
  • Page 12: Specifications

    Hearthstone Quality Home Heating Products, Inc. Bristol DX Model 8762 Specifications : Gas-Fired Direct-Vent Fireplace Heater Certified for use by: ISTED Model: Bristol Direct-Vent Gas Fireplace Board of State Examiners of Plumbers & Gasfitters Heater (8762) 100 Cambridge Street, Room 1511...
  • Page 13: Installation Preparation

    The appliance when installed must be electrically Packing List connected and grounded in accordance with local 1- Bristol DX 8762 Gas-Fired Heater codes or, in the absence of local codes, with the 1- Owner’s Packet Envelope (manual, warranty card) current NFPA 70-National Electrical Code or CSA 5- Decorative Ceramic Logs (in box on pallet) C22.1-Canadian Electric Code.
  • Page 14 Hearthstone Quality Home Heating Products, Inc. Bristol DX Model 8762 damage is found or suspected, contact your dealer for instructions. Always use gloves and eye protection when handling Shipping Stand the decorative ceramic fire logs, and burner. Use care when handling these parts as they are fragile and subject to damage and breakage if handled roughly.
  • Page 15 Hearthstone Quality Home Heating Products, Inc. Bristol DX Model 8762 Firebox Access 4. Pull forward and disengage the spring clips securing the top of the glass frame. See Figure 1. First, remove the top of the stove (lift off). Set 14.
  • Page 16: Clearances To Combustibles

    Hearthstone Quality Home Heating Products, Inc. Bristol DX Model 8762 Clearances to Combustibles Note: Ensure clearances are in accordance with local installation codes requirements of the gas supplier. Clearance to Combustibles Due to high surface temperatures, locate the unit out of traffic areas and away from furniture and draperies.
  • Page 17 Hearthstone Quality Home Heating Products, Inc. Bristol DX Model 8762 The corner clearance for the Bristol 8762 is 11”, measured from the edge of the top castings, to the adjacent wall. Figure 16 - Corner Clearance...
  • Page 18: Venting Information

    Hearthstone Quality Home Heating Products, Inc. Bristol DX Model 8762 Venting Information Approved Venting Configurations Venting Components WARNING: HIGH WIND AREAS Starter collar is installed by Hearthstone. PARTICULARLY COLD CLIMATES IT MAY BE Use the following instructions along with the pipe NECESSARY TO HEAT YOUR VENT SYSTEM manufacturer’s...
  • Page 19 Hearthstone Quality Home Heating Products, Inc. Bristol DX Model 8762 All termination caps must be no less than 18” The liner must have an inside dimension or diameter 6” or greater. (457mm) horizontally from any roof or vertical surface. See Figure 18.
  • Page 20: Horizontal Termination

    Hearthstone Quality Home Heating Products, Inc. Bristol DX Model 8762 Horizontal Termination All horizontal terminations must also comply with clearance specifications adjacent The termination must fall within the area shown structures outlined in Figures 18 and 20. in Figures 18 & 20.
  • Page 21 Hearthstone Quality Home Heating Products, Inc. Bristol DX Model 8762 Figure 19 - Acceptable Direct Vent Terminal Vent Cap Locations A = Clearance above grade, veranda, porch, deck, H = *Not to be installed within 15 feet (4.5m) above or balcony: 12 inches (30cm) minimum.
  • Page 22: Minimum Venting Installation Instructions

    Hearthstone Quality Home Heating Products, Inc. Bristol DX Model 8762 thimble cover will fit properly. Screw the thimble Minimum Venting Installation cover to the wall. Instructions 1. Install the 36” pipe section onto the starter collar by fully inserting it and turning approximately ¼...
  • Page 23 Hearthstone Quality Home Heating Products, Inc. Bristol DX Model 8762 The restrictor consists of a sliding plate just below Restrictor Plate the venting starter collar on the top rear of the The restrictor plate is used to control excess draft if firebox.
  • Page 24 Hearthstone Quality Home Heating Products, Inc. Bristol DX Model 8762 Figure 23 - Venting Termination Diagram...
  • Page 25: Electrical System Information

    Hearthstone Quality Home Heating Products, Inc. Bristol DX Model 8762 Electrical System Information CAUTION: LABEL ALL WIRES PRIOR TO DISCONNECTION WHEN SERVICING CONTROLS. WIRING ERRORS CAN CAUSE IMPROPER AND DANGEROUS OPERATION. VERIFY PROPER OPERATION AFTER SERVICING. (ATTENTION: AU MOMENT DE L’ENTRETIEN DES COMMANDES, ÉTIQUETEZ TOUS LES FILS AVANT LE DÉBRANCHEMENT.
  • Page 26: Gas Supply & Connections

    Hearthstone Quality Home Heating Products, Inc. Bristol DX Model 8762 Gas Supply & Connections NOTE: Ensure the gas line is installed as close to the floor as possible to avoid interference or conflict with a blower assembly installation. Figure 25 - Gas Control Valve...
  • Page 27: Gas Connections

    Hearthstone Quality Home Heating Products, Inc. Bristol DX Model 8762 If the installer must convert the unit to adjust for Gas Connections varying altitudes, the information sticker (similar to The gas supply connection is made to the Bristol’s the one shown in Figure 28) must be filled out by the...
  • Page 28: Log Set, & Screen Placement

    Hearthstone Quality Home Heating Products, Inc. Bristol DX Model 8762 Log Set, & Screen Placement CAUTION: FRAGILE! HANDLE LOG SET WITH CARE. ALWAYS WEAR GLOVES AND SAFETY GOGGLES WHILE HANDLING THE LOG SET. WARNING: Failure to position the burner and logs...
  • Page 29: Installation Of The Optional Screens

    Hearthstone Quality Home Heating Products, Inc. Bristol DV Model 8762 5. Place log 4 on top of logs 1 as shown. Photo 8 – Log Set Detail, Top View Photo 5 – Log 4 in Position Installation of the Optional 6.
  • Page 30: Lighting & Operation

    Hearthstone Quality Home Heating Products, Inc. Bristol Model 8762 Lighting & Operation WARNING: IF YOU DO NOT FOLLOW THESE INSTRUCTIONS EXACTLY, FIRE Using the Remote: EXPLOSION MAY RESULT CAUSING PROPERTY Remote Control Board must DAMAGE, PERSONAL INJURY OR LOSS OF LIFE. synchronized before initial use, and after every CAUTION: LIGHTING THE BRISTOL FOR THE battery change (for instructions, see page 35).
  • Page 31: Initial Adjustments

    Hearthstone Quality Home Heating Products, Inc. Bristol Model 8762 Odors and Impurities A heater of this type may produce odors during heater operation at any time due to impurities that may exist in the immediate area around the unit. Sources of impurities can be cleaning solvents, paint solvents, cigarettes, candles, smoke, pet hair, dust, adhesives, new carpet, and/or textiles.
  • Page 32: Daily Operation

    Hearthstone Quality Home Heating Products, Inc. Bristol Model 8762 Some conditions cannot be corrected through air Note: Very little movement is needed to substantially shutter adjustment; an adjustment must be made to change the burn and flame patterns. Some the gas supply pressure or by changing the conditions cannot be corrected through air shutter restriction plate setting.
  • Page 33 Hearthstone Quality Home Heating Products, Inc. Bristol Model 8762 ON/REMOTE/OFF switch on the Receiver or by the During the summer non-heating season, switch the unit “OFF”, and flip the pilot switch to Intermittent Remote Control. (IPI). This will improve the overall efficiency of the With the Manual switch set to ‘REMOTE’...
  • Page 34: Routine Maintenance & Care

    Hearthstone Quality Home Heating Products, Inc. Bristol Model 8762 Routine Maintenance & Care Your Bristol requires minimal routine maintenance Annually: and care. Ensure the unit is cool and off when cleaning, or servicing. Clean Firebox, Pilot, & Burner Assembly WARNING: DO NOT SUBSTITUTE MATERIALS. The firebox requires periodic cleaning to prevent the accumulation of dust, lint, and other debris.
  • Page 35: As Needed

    Hearthstone Quality Home Heating Products, Inc. Bristol Model 8762 Battery Replacement instructions provided in this manual, or by the specific venting manufacturer. WARNING: DISCONNECT POWER TO THE UNIT AND SHUT OFF THE GAS SUPPLY TO THE As Needed: VALVE BEFORE REPLACING ANY BATTERIES. Hearthstone recommends replacing all batteries at Glass and Gasket Replacement least every season.
  • Page 36 Hearthstone Quality Home Heating Products, Inc. Bristol Model 8762 Clean off as much of the hanging fiber “hairs” as 3. Dismount the front glass assembly by releasing the upper spring clips – then lift the frame up possible and out of the lower mounting points. 8.
  • Page 37: Parts List

    Hearthstone Quality Home Heating Products, Inc. Bristol Model 8762 Parts List Part # Description Part # Description 27XX-740 5710-307 Pilot Shield 27XX-730 Front 5710-305 Firebox Bottom Pan 27XX-725 Right Side 5710-304 Firebox 27XX-720 Left Side 5710-303 Base Plate 27XX-710 Control Door 5710-279 Glass Handle, Spring Hook 27XX-700...
  • Page 38: Troubleshooting

    Hearthstone Quality Home Heating Products, Inc. Bristol Model 8762 Troubleshooting Symptom Possible Cause Corrective Action 1. Pilot will not light. A. Power supply not plugged in A. Ensure power supply is plugged in and receiving 120V and/or batteries are dead. AC.
  • Page 39 Hearthstone Quality Home Heating Products, Inc. Bristol Model 8762 Symptom Possible Cause Corrective Action 5. Frequent pilot outage A. Pilot flame may be too low or A. Clean and/or adjust the pilot flame for maximum problem in CPI mode. blowing, (high), causing the pilot impingement on the rectification sensor.
  • Page 40: Rating Label

    Hearthstone Quality Home Heating Products, Inc. Bristol Model 8762 Rating Label...
  • Page 41: Warranty Registration

    Hearthstone Quality Home Heating Products, Inc. Bristol Model 8762 WARRANTY REGISTRATION The Original Purchaser can complete their warranty registration on our website at www.hearthstonestoves.com, or send a completed and signed Warranty Registration Form, which is enclosed in the Gas Stove warranty packet, to the following address: Hearthstone Quality Home Heating Products, Inc.
