Owner's Manual & Installation Guide
Stowe
for the
DIRECT VENT HEATER
WARNING:
If
the
instructions is not followed exactly, a fire or
explosion may result causing property damage,
personal injury or loss of life.
Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any
other appliance.
WHAT TO DO IF YOU SMELL GAS:
Do not try to light any appliance.
Do not touch electrical switches; do not use
the phone in your building.
Immediately call your gas supplier from a
neighbors phone. Follow your gas suppliers
instructions.
If you cannot reach your gas supplier, call the
fire department.
A qualified installer, service agency or gas supplier
must perform installation and service.
GAS-FIRED
(8320)
information
in
these
READ THIS OWNER'S
MANUAL
Operate and maintain this gas heater
according to this instruction manual.
Read This Manual In Its Entirety.
AVERTISSEMENT: Assurez-vous de bien suivre
les instructions donné dans cette notice pour
réduire au minimum le risque d'incendie ou pour
éviter tout dommage matéeriel, toute blessure ou la
mort.
Ne pas entresposer ni utiliser d'essence ni d'autre
vaperurs
ou
liquides
voisinage
de cet apprareil ou de tout autre appareil.
QUE FAIRE
SI
ODEUR
DE GAZ:
Ne pas tenter d'allumer d'appareil.
Ne touchez à aucun interrupteur. Ne pas vous
servir des téléphones se trouvant dans le
batiment où vous vous trouvez.
Appelez immédiatement votre fournisseur de
gaz depuis un voisin. Suivez les instructions
du fournisseur.
Si vous ne pouvez rejoindre le fournisseur de
gaz, appelez le service dos incendies.
L'installation et service doit être exécuté par un
qualifié
installer,
agence
fournisseur de gaz.
inflammables
dans
VOUS
SENTEZ
UNE
de
service
ou
Model #8320
6400-40422
05-22-03
le
le
