(Model 8180)
Gas Fired Direct-Vent Heater
Owner's Manual
INSTALLATION AND
OPERATING INSTRUCTIONS
PLEASE READ THIS ENTIRE OWNER'S
MANUAL BEFORE YOU INSTALL AND USE
YOUR NEW BARI GAS HEATER. SAVE THIS
DOCUMENT FOR FUTURE REFERENCE.
AVERTISSEMENT:
SUIVRE LES INSTRUCTIONS DONNÉ DANS CETTE
NOTICE POUR RÉDUIRE AU MINIMUM LE RISQUE
D'INCENDIE OU POUR ÉVITER TOUT DOMMAGE
MATÉERIEL, TOUTE BLESSURE OU LA MORT.
AVERTISSEMENT: NE PAS ENTRESPOSER NI
UTILISER D'ESSENCE NI D'AUTRE VAPERURS OU
LIQUIDES INFLAMMABLES DANS LE VOISINAGE
DE CET APPRAREIL OU DE TOUT AUTRE
APPAREIL.
QUE FAIRE SI VOUS SENTEZ UNE ODEUR DE GAZ:
Ne pas tenter d'allumer d'appareil.
Ne touchez à aucun interrupteur. Ne pas vous servir
des téléphones se trouvant dans le batiment où vous
vous trouvez.
Appelez immédiatement votre fournisseur de gaz
depuis un voisin.
fournisseur.
Si vous ne pouvez rejoindre le fournisseur de gaz,
appelez le service dos incendies.
L'installation et service doit être exécuté par un qualifié
installer, agence de service ou le fournisseur de gaz.
ASSUREZ-VOUS
DE
Suivez les instructions du
Bari DV Gas Model 8180
Manual # 6400-40458
R: 4 - 6/30/2011
BIEN
