OWNER'S MANUAL
READ THIS OWNER'S MANUAL
Operate and maintain this gas heater according to instructions in this manual. Read this manual in its
entirety.
WARNING
If the information in this manual is not followed exactly, a fire or explosion may result, causing property
damage, personal injury or loss of life.
Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other
appliance.
Installation and service must be performed by a qualified installer, service agency or the gas supplier.
This is an un-vented gas-fired heater. It uses air (oxygen) from the room in which it is installed.
Provisions for adequate combustion and ventilation air must be provided. Refer to page 6 of this
manual.
FOR YOUR SAFETY - WHAT TO DO IF YOU SMELL GAS
* DO NOT ATTEMPT TO LIGHT THIS GAS HEATER OR ANY APPLIANCE
* EXTINGUISH ANY OPEN FLAME
* DO NOT TOUCH ANY ELECTRICAL SWITCH
* DO NOT PLUG IN OR UNPLUG ANY APPLIANCE
* DO NOT USE ANY PHONE IN YOUR BUILDING
* OPEN WINDOWS IN THE ROOM AND VACATE THE BUILDING
* TURN OFF THE MAIN GAS SUPPLY
* IMMEDIATELY CALL YOUR GAS SUPPLIER FROM A NEIGHBOR'S PHONE
* FOLLOW THE GAS SUPPLIERS INSTRUCTIONS
* IF YOU CANNOT REACH YOUR GAS SUPPLIER, CALL THE FIRE DEPARTMENT
TUCSON
Heater
(8745)
Manufactured by
HearthStone
317 Stafford Avenue
Morrisville, Vermont 05661
Gas-Fired Vent-Free
6400-40440 05-22-03
Advertisement
Table of Contents
Related Manuals for HearthStone TUCSON 8745
Summary of Contents for HearthStone TUCSON 8745
-
Page 1: Read This Owner's Manual
OWNER’S MANUAL TUCSON Gas-Fired Vent-Free Heater (8745) Manufactured by HearthStone 317 Stafford Avenue Morrisville, Vermont 05661 READ THIS OWNER’S MANUAL Operate and maintain this gas heater according to instructions in this manual. Read this manual in its entirety. WARNING If the information in this manual is not followed exactly, a fire or explosion may result, causing property damage, personal injury or loss of life. -
Page 2: Service Record
INFORMATION SHEET Record, on this page, all relevant information concerning the purchase, installation, and maintenance of your Tucson gas-fired heater. This information will facilitate servicing, purchase of replacement parts, and warranty claims (if necessary). Keep your original receipt in a safe place as proof of purchase. Serial Number: Fuel type (check one) Natural Gas... -
Page 3: Table Of Contents
Congratulations purchase your with any gas appliance, the unit must be properly HearthStone Tucson Gas-Fired Vent-Free Stove. installed and maintained by qualified service The Tucson incorporates the latest in energy and personnel to ensure safe and trouble -free gas technology, which will provide you with operation. -
Page 4: Safety Information
OWNER’S MANUAL MODEL: 8745 TUCSON Vent-Free HEATER The installation must conform with local codes or, in the absences of local codes, the current National Fuel SAFETY INFORMATION Gas Code, ANSI Z223.1 (NFPA 54). Your Tucson Vent-Free is very attractive and extremely efficient, utilizing today’s best technologies. - Page 5 Use of any components not supplied lit by using a piezoelectric spark generator, as described by HearthStone on the stove voids all warranties. in the How To Turn the Unit On & Off section of this Do not substitute components.
-
Page 6: Clearances To Combustibles
OWNER’S MANUAL MODEL: 8745 TUCSON Vent-Free HEATER Always maintain adequate clearances around the air CLEARANCES TO COMBUSTIBLES openings into the combustion chamber and allow for adequate ventilation. Minimum clearances Due to high surface temperatures, the Tucson should combustibles must be maintained as shown to the be located out of traffic and away from furniture and right, Figure... -
Page 7: Fresh Air Requirements
OWNER’S MANUAL MODEL: 8745 TUCSON Vent-Free HEATER FRESH AIR REQUIREMENTS Your Tucson stove requires an adequate supply of 1. Unusually tight construction fresh air to function properly and safely. The fresh 2. Unconfined space air supply must be met within the space in which the 3. - Page 8 OWNER’S MANUAL MODEL: 8745 TUCSON Vent-Free HEATER maximum BTU/hr rating of the combined appliances (from III.). If the number from III. is smaller than the number calculated in II., the space should be considered an unconfined space. If the number from III.
- Page 9 OWNER’S MANUAL MODEL: 8745 TUCSON Vent-Free HEATER MEETING FRESH AIR REQUIREMENTS 1. Air from inside the building. The confined space shall be provided with two permanent openings communicating directly with an additional room(s), of sufficient volume, so that the combined volume of all spaces meets the criteria for an unconfined space.
- Page 10 OWNER’S MANUAL MODEL: 8745 TUCSON Vent-Free HEATER PACKING LIST & ITEMS REQUIRED FOR INSTALLATION Packing list Items Required For Installation Ensure that the following items are available before proceeding with installation: 1 - Tucson Vent-Free Gas-Fired Heater 5/32 Allen wrench 4 - Decorative Ceramic Fiber Logs An external regulator (for propane/ L.
-
Page 11: Electrical Connections
OWNER’S MANUAL MODEL: 8745 TUCSON Vent-Free HEATER ELECTRICAL CONNECTIONS NOTE: OPEN VALVE DOOR UNDER ASH LIP FOR ELECTRICAL AND GAS CONNECTIONS Thermostat Wiring The thermostat wire from the unit to the thermostat Thermostat can be surface mounted, routed under the floor, or The Tucson may use the wall mounted thermostat for through walls, etc. -
Page 12: Gas Supply & Connections
OWNER’S MANUAL MODEL: 8745 TUCSON Vent-Free HEATER GAS SUPPLY & CONNECTIONS the unit without undue loss of pressure. Gas Supply recommend a flexible line to avoid undue mechanical NOTICE: A qualified technician must connect the load on the valve and to ease thread alignment, but heater to the gas supply and leak test the unit also refer to local code. -
Page 13: Log Set Information
OWNER’S MANUAL MODEL: 8745 TUCSON Vent-Free HEATER LOG SET INFORMATION CAUTION: Fragile! Handle log set and ember strip with care. Always wear gloves and safety goggles while handling the log set and the ember strip. Log Placement Within The Unit Only the decorative ceramic fiber log set supplied with the unit should be placed in the firebox. -
Page 14: Before The Stove Is Lit
OWNER’S MANUAL MODEL: 8745 TUCSON Vent-Free HEATER holes that will slide over the two posts in the bottom Removal of Log Set of the firebox The rear tabs on the Middle Log CAUTION: Log set and charcoal embers retain heat should touch the front of the Rear Log, and the log and can be very hot! Allow 2 to 3 hours after pilot should be centered as best as possible. -
Page 15: How To Turn The Unit On & Off
OWNER’S MANUAL MODEL: 8745 TUCSON Vent-Free HEATER Odors and Impurities A Vent-Free combustion system is such that odors Pilot Light Warning may be produced during heater operation due to The Tucson has a piezoelectric spark ignitor (the impurities that may exist in the immediate area. red push button located next to the gas control valve Sources of impurities can be cleaning solvents, behind the valve access door) which ignites the... -
Page 16: Burner Flame Appearance
OWNER’S MANUAL MODEL: 8745 TUCSON Vent-Free HEATER * If the knob does not pop out when released, control knob while pressed in the “PILOT” stop and immediately call a qualified service position, wait 60 seconds for the Interlock to technician or gas supplier. release. -
Page 17: Initial Adjustments
OWNER’S MANUAL MODEL: 8745 TUCSON Vent-Free HEATER INITIAL ADJUSTMENTS determine the location of the pilot adjustment Variable Output Control The gas control valve is equipped with a variable screw. output control. This control varies the rate of heat produced by the unit by varying the gas pressure to Note that the pilot flame must engulf the thermopile the main burner tube. -
Page 18: Routine Maintenance And Care18
For replacement parts, or for information about the unit according to lighting instructions described parts or service, contact your local HearthStone in the How To Turn the Unit On & Off section of dealer. -
Page 19: Parts List
Morrisville, Vermont 05661 WARNING: Do not substitute Materials. E-Mail:HearthStone@HearthStoneStoves.com For replacement parts, or for information about parts or service, contact your local HearthStone dealer. For the name of the dealer nearest to you, phone or write: PARTS LIST Part #... - Page 20 OWNER’S MANUAL MODEL: 8745 TUCSON Vent-Free HEATER Natural Gas Input rating (Btu/hr) 20,000 20,000 Minimum input rating (Btu/hr) 13,500 16,000 Orifice size DMS Man. pressure-HI setting (in. w.c./kPa) 10.0 Man. Pressure-Lo setting (in.w.c./kPa) Inlet pressure-LO (in. W.c./kPa) 11.0 -20-...
-
Page 21: Troubleshooting
OWNER’S MANUAL MODEL: 8745 TUCSON Vent-Free HEATER TROUBLESHOOTING Symptom Possible Cause Corrective Action; 1. Pilot will not light. A. Insufficient gas pressure, A. Using the piezo sparker, try to light the pilot. air in the pilot line, or dirty or If it will not light, check the inlet gas pressure. - Page 22 OWNER’S MANUAL MODEL: 8745 TUCSON Vent-Free HEATER TROUBLESHOOTING cont. Symptom Possible Cause Corrective Action 5. Frequent pilot outage A. Pilot may be too low or A. Clean and/or adjust the pilot flame for problem. blowing, (high), causing the pilot maximum impingement on the thermopile safety to drop out.
- Page 23 Original Purchaser purchases the Stove (the “Purchase Date”). LIMITED LIFETIME WARRANTY HearthStone warrants the following parts of the Stove against the following occurrences that result from defects in material and workmanship: All cast iron parts, including the cast iron heat exchanger – against breakage, cracking or burn-through.
- Page 24 9. A defect in any part of the Stove if the Original Purchaser fails to comply with HearthStone’s or a Dealer’s request to ship the part or the Stove to HearthStone or a Dealer, as the case may be.
-
Page 25: Warranty Registration
MODEL: 8745 TUCSON Vent-Free HEATER a Dealer to make a service call, HearthStone or a Dealer, as the case may be, will request that the Original Owner return the defective part, or the entire Stove (if needed), with shipping prepaid, to HearthStone or a Dealer.
