IP ADDRESSING
5–4
Likewise, the argument is valid only with the bootp type. This option allows the
bootcfg
switch to load the configuration file from the bootp server. This is useful when a new
switch is put on a network and the specific configurations are loaded from a centralized
bootp server
The following example changes the boot mode of the switch:
ML3000#
set bootmode type=bootp bootimg=enable bootcfg=disable
Network application image download is enabled.
Network application config download is disabled.
Save Configuration and Restart System
ML3000#
Alternatively, the DHCP/bootp/manual can be enabled through the EnerVista Secure Web
Management software as shown below.
 Select the Administration > System menu item.
 Click Edit.
 Alternatively, select items in the Administration > Set menu to
individually modify the boot mode, date and time, log size, etc.
