CHAPTER 19: MODBUS PROTOCOL
Table 19–1: Modbus memory map (Sheet 16 of 33)
Address
Description
0358
Port 13: Number of dropped received
packets
035A
Port 13: Number of multicast frames
sent
035C
Port 13: Number of broadcast frames
sent
035E
Port 13: Number of <64 byte fragments
with good CRC
0360
Port 14: Number of bytes received
0362
Port 14: Number of bytes sent
0364
Port 14: Number of frames received
0366
Port 14: Number of frames sent
0368
Port 14: Total bytes received
036A
Port 14: Total frames received
036C
Port 14: Number of broadcast frames
received
036E
Port 14: Number of multicast frames
received
0370
Port 14: Number of frames with CRC
error
0372
Port 14: Number of oversized frames
received
0374
Port 14: Number of bad fragments
received (<64 bytes)
0376
Port 14: Number of jabber frames
received
0378
Port 14: Number of collisions occurred
037A
Port 14: Number of late collisions
occurred
037C
Port 14: Number of 64-byte frames
received/sent
037E
Port 14: Number of 65 to 127 byte
frames received/sent
0380
Port 14: Number of 128 to 255 byte
frames received/sent
0382
Port 14: Number of 256 to 511 byte
frames received/sent
0384
Port 14: Number of 512 to 1023 byte
frames received/sent
0386
Port 14: Number of 1023 to maximum
byte frames received/sent
0388
Port 14: Number of MAC error packets
038A
Port 14: Number of dropped received
packets
038C
Port 14: Number of multicast frames
sent
038E
Port 14: Number of broadcast frames
sent
MULTILINK ML3000 ETHERNET COMMUNICATIONS SWITCH – INSTRUCTION MANUAL
Range
Step
Format
0 to
1
F9
4294967295
0 to
1
F9
4294967295
0 to
1
F9
4294967295
0 to
1
F9
4294967295
0 to
1
F9
4294967295
0 to
1
F9
4294967295
0 to
1
F9
4294967295
0 to
1
F9
4294967295
0 to
1
F9
4294967295
0 to
1
F9
4294967295
0 to
1
F9
4294967295
0 to
1
F9
4294967295
0 to
1
F9
4294967295
0 to
1
F9
4294967295
0 to
1
F9
4294967295
0 to
1
F9
4294967295
0 to
1
F9
4294967295
0 to
1
F9
4294967295
0 to
1
F9
4294967295
0 to
1
F9
4294967295
0 to
1
F9
4294967295
0 to
1
F9
4294967295
0 to
1
F9
4294967295
0 to
1
F9
4294967295
0 to
1
F9
4294967295
0 to
1
F9
4294967295
0 to
1
F9
4294967295
0 to
1
F9
4294967295
MODBUS PROTOCOL
Default
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
19–19
