PORT MIRRORING & SETUP
Example 9-1: Port setup
ML3000#
ML3000(device)##
ML3000(device)##
ML3000(device)##
Keys: E = Enable
Port Name
-------------------------------------------------------------------------------
9 B1
10 B2
11 JohnDoe E
12 JaneDoe E
13 B5
14 B6
15 B7
16 B8
9–4
In Example 9-1, ports 11 and 12 are given specific names. Ports 9 and 13 are active, as
shown by the link status. Port 13 is set to 100 Mbps, and all other ports are set to 10 Mbps.
All ports are set to auto sensing (speed).
The port and
speed duplex
The setting defaults to auto and senses speed and negotiates with the port at the
speed
other end of the link for data transfer operation (half-duplex or full-duplex). The "auto"
speed detection uses the IEEE 802.3u auto negotiation standard for 100Base-T networks. If
the other device does not comply with the 802.3u standard, then the port configuration on
the switch must be manually set to match the port configuration on the other device.
Possible port setting combinations for copper ports are:
• 10HDx: 10 Mbps, half-duplex
• 10FDx: 10 Mbps, full-duplex
• 100HDx: 100 Mbps, half-duplex
• 100FDx: 100 Mbps, full-duplex
Possible port settings for 100FX (fiber) ports are:
• 100FDx (default): 100 Mbps, full-duplex
• 100HDx: 100 Mbps, half-duplex
Possible port settings for 10FL (fiber) ports are:
• 10HDx (default): 10 Mbps, half-duplex
• 10FDx: 10 Mbps, full-duplex
Gigabit fiber-optic ports (Gigabit-SX and Gigabit-LX):
• 1000FDx (default): 1000 Mbps, full-duplex only
• Auto: The port operates at 1000FDx and auto-negotiates flow control with the
connected device.
device
setport port=11 name=JohnDoe
setport port=12 name=JaneDoe
show port
D = Disable
H = Half Duplex F = Full Duplex
M = Multiple VLAN's NA = Not Applicable
LI = Listening LE = Learning
F = Forwarding B = Blocking
Control Dplx Media Link Speed Part Auto VlanID GVRP STP
E H 10Tx UP 10
E H 10Tx DOWN 10
H 10Tx DOWN 10
H 10Tx DOWN 10
E F 100Tx UP 100 No E
E H 10Tx DOWN 10
E H 10Tx DOWN 10
E H 10Tx DOWN 10
MULTILINK ML3000 ETHERNET COMMUNICATIONS SWITCH – INSTRUCTION MANUAL
CHAPTER 9: PORT MIRRORING & SETUP
(data transfer operation) settings are summarized below.
No E 1 - -
No E 1 - -
No E 1 - -
No E 1 - -
1 - -
No E 1 - -
No E 1 - -
No E 1 - -
