11.2

Field Replaceable Units

Note – The procedures in this chapter for replacing faulty components are for the
attention of qualified service engineers only. If you need to replace a component,
contact your local Sun sales representative who will put you in touch with the Sun
Enterprise Service branch for your area. You can then arrange to return the system to
Sun for repair under the terms of your warranty. Or alternatively you can order the
components and have them installed by your own qualified service engineers.
TABLE 11-1
FRUs are hardware components that are normally installed by Sun engineers and
not by users.
TABLE 11-1
Component
Internal CD-ROM (including cabling and paddle board)
18 Gbyte hard disk drive
256 Mbyte DIMM
512 Mbyte DIMM
System board (including CPU and fan)
Memory card reader (for the system configuration card)
AC power supply
DC power supply
Rear fan subassembly (containing Fans 1 and 2)
System configuration card
Fan 3 (CPU fan)
NVRAM chip (including carrier)
Note – Except for the 18 Gbyte hard disk, you can only use the FRUs in this list in
Netra T1 AC200 and DC200 servers. They are not for use in the earlier Netra t1
Model 100 or Model 105 servers.
For instructions about how to install DIMMs, see Chapter 4.
11-4 Netra T1 AC200 and DC200 Server User's Guide • August 2001
lists the field replaceable units (FRUs) available for the Netra T1 server.
FRUs Available for the Netra T1 AC200 and DC200 Servers
Part Number
F370-4278
F540-4177
F370-4237
F370-4281
F375-0132
F370-4290
F300-1488
F300-1489
F370-4284
F370-4285
F370-4352
F100-6889
