Dip 8 sets if GYDA-SC is able to configure or not. When GYDA-SC override is set, the actual
setting can be read by using the info command (se GYDA-SC user manual for details).

3.2 GYDA-SC control

Latest configuration from GYDA-SC is stored local on card. This prevents configuration loss
during power recycling.
The card supports Flashlink protocol v4.0.

3.2.1 Block descriptions

Supported block command.
3.2.1.1 Laser
<identifier> ::= 'lsr'
<status> ::= 'D' [<wavelength>'nm'] [<power>'dBm'] ['on'|'off'] ['ok|fail'] ['tempfail'|'stab']
<block command> ::= <operation>
<operation> ::= 'on'|'off'
3.2.1.2 PIN
<identifier> ::= 'pin'
<status> ::= ['cd'|'ncd']
3.2.1.3 Voltage
<identifier> ::= 'pwr'
<status> ::= [<nominal voltage>'Vnom'] [<voltage>]
3.2.1.4 General output
<identifier> ::= 'gpi'
<status> ::= ['out'] ['act'|'inact'] ['thru'] ['id' '"'<GPI identifier>'"']
<block command> ::= <set state>
<set state> ::= 'act'|'inact'|'thru'
3.2.1.5 Ethernet port
<identifier> ::= 'ethp'
<status> ::= ['dis'|'en'] ['cd'|'ncd'] [('10'|'100'|'1000') ('man'|'auto')] [('full'|'half') ('auto')]
[('mdi|mdix') ('auto')] [('mas'|'sla') ('auto')]
<block command> ::= 'dis'|'en'| <speed mode>
<speed mode> ::= 'speed' '10'|'100'|'1000'|'auto'
3.2.1.6 Misc
<identifier> ::= 'misc'
<status> ::= ['prog'|'fin'] ['ovr']
