ETH1000-D

4 Connector module

The ETH1000D has a dedicated connector module: ETH1000-C1. This module is mounted at
the rear of the sub-rack. The module is shown in the figure below.

4.1 Mounting the connector module

The details of how the connector module is mounted, is found in the user manual for the sub-
rack frame FR-2RU-10-2.
This manual is also available from our web site:
http://www.network-electronics.com/.
OPT TX
GPI
OPT RX
10/100/1000Base-T
network-electronics.com | 8
Rev. 1
