Specifications

General
Channels
Frequency band
Frequency control
Operatine temperature
DC input voltage
Size
Weight
Receiver
System
IF
Sensitivity
Audio output
Audio distorsion
Image rejection
Adjacent channel
Signal/noise ratio
Current drain
Transmitter
System
Maximum RF power
Modulation
Impedance
Current drain
Specifications
Refer to the frequency bands table at page 12
27 MHz Citizen Band
P.L.L.
-10°/+55°C
9.0V (6 x AAA 1.5V alkaline battery)
7.2V (6 x AAA 1.2V Ni-MH battery)
68 (L) x 146 (H) x 38 (D) mm
218 gr. (without batteries and antenna)
Double conversion, CPU controlled super-eterodine
1° 10.695 MHz / 2° 455 KHz
0.5uV for 20dB SINAD (FM)
0.7uV for 20dB SINAD (AM)
0.3W at 8 ohm
<8% at 1 KHz
61dB
61dB
45dB
70mA (stand-by)
CPU controlled P.L.L. systhesizer
4W at 9.0Vdc
AM/FM
50 ohm unbalanced
1500mA (at no modulation)
