Specifications

General
Channels
Frequency range
Frequency control
Operatine temperature
DC input voltage
Size
Weight
Receiver
System
IF
Sensitivity
Audio output
Audio distorsion
Image rejection
Adjacent channel
Signal/noise ratio
Current drain
Transmitter
System
Maximum RF power
Modulation
Impedance
Current drain
Specifications
40 FM (refer to the frequency bands table at page 10)
25.610 – 31.570 MHz
P.L.L.
-10°/+55°C
13.2Vdc ±15%
180 (L) x 50 (A) x 153 (P) mm
1.0 kg
Double conversion, CPU controlled super-eterodine
1° 10.695 MHz / 2° 455 KHz
0.5uV for 20dB SINAD (FM)
0.5uV for 20dB SINAD (AM)
@10% THD 2.5W at 8 ohm
<8% at 1 KHz
65dB
65dB
45dB
250mA (stand-by)
CPU controlled P.L.L. systhesizer
4W at 13.2Vdc
85% to 90% (AM)
1.8 KHz ±0.2 KHz (FM)
50 ohm unbalanced
1100mA (at no modulation)
