Installing and Checking Batteries
Slide down and remove the battery door (24) and to access the battery room. Set the battery type switch (25)
according to the type of used batteries (Ni for rechargeable batteries and AL for alkaline batteries). Install 6 x AA size
alkaline batteries or rechargeable batteries and pay attention to install it with the correct polarity as indicated in the
battery room. Switch ON radio by turning the OFF/VOL (3) control and check the battery level on the battery level
indicator (N), 4 bars mean full charge, 3 bars mean normal charge, 2 bars mean half charge and 1 bar means low
battery condition. If no bars appear, batteries must be immediately replaced or recharged. Please refer to the
following item BATTERY CHARGING.
Battery Charging
If the battery level indicator (N) shows a low battery condition, switch OFF the radio and connect the battery travel
charger mod. AC-520 to the CHARGE jack (22), then plug it into the 230VAC outlet. To obtain the maximum
performance from the batteries, recharge them only when they are fully discharged. The charging time depends on the
capacity of the used batteries, it is approximately 12 hours for one set of Ni-MH batteries (1200-1500mAh). When the
charging time has expired, unplug the charger from the AC outlet and then disconnect it from the radio.
WARNING !
1. Only the Ni-MH (or Ni-CD) batteries may be recharged.
2. Do never try to recharge alkaline batteries, as this might cause damage to the radio or explosion of the
batteries.
3. Set the battery type selector (25) to Ni.
4. Always switch OFF radio before starting the battery charging process.
5. Do not recharge batteries for more than 13-14 hours, in order to avoid overcharge or overheating, which could
cause damage to the radio.
6. Use only the enclosed battery charger or original INTEK battery chargers.

Battery Operation
