5
4
3
1. ANTENNA SOCKET
2.
ACCESSORIES SOCKET: External microphone
444. NOTE : never use the transceiver with the socket cover removed. Dust and
other foreign material can damage the transceiver.
3.
VOLUME ON/OFF :
level.
4.
CHANNEL SELECTOR
5.
PROGRAMMABLE BUTTON (RED) : Pressing this button for longer than
seconds locks the keypad, a key symbol is displayed. To unlock, press again for more
than 2 seconds.
Guideline Télécom MSFB
TOP VIEW
6
allows to turn transceiver on or off and to adjust volume
Technical Sheets
1
2
EM-81 or cloning cable OPC-
ICOM IC-F30 LT
05/08/2002
2
6
