Assembly and Operating Instructions for Outback®
Trooper/Hunter/Ranger Stainless Steel Gas Barbecues
Photographs are not to scale.
Specifications subject to change
without prior notice.
•
•
•
•
•
•
WARNING
•
•
•
FOR YOUR SAFETY
If you smell gas:
1.
Shut off gas to the appliance.
2.
Extinguish any open flame.
3.
Open barbecue lid or hood.
4.
If odour continues, discontinue use and
contact your local dealer.
Gas Barbecues
For outdoor use only. Not for commercial use.
Read instructions before using the appliance. Failure to follow instructions could
result in death, serious bodily injury, and/or property loss.
Warning: accessible parts may be very hot. Keep young children away.
Do not move the appliance during use.
Turn off the gas supply at the gas bottle after use.
Any modification of the appliance, misuse, or failure to follow the instructions may
be dangerous and will invalidate your warranty. This does not affect your statutory
rights.
Retain these instructions for future reference.
Leak test annually, and whenever the gas bottle is removed or replaced.
For Flare-up control please refer to the 'OPERATION' section of this manual.
1.
2.
FOR YOUR SAFETY
Do not store or use petrol or other flammable
vapours or liquids in the vicinity of this or any
other appliance.
A gas bottle not connected for use shall not be
stored in the vicinity of this or any other
appliance.
EN (Europe)
0359
Advertisement
Table of Contents
Related Manuals for Outback Trooper Stainless Steel
Summary of Contents for Outback Trooper Stainless Steel
-
Page 1: For Your Safety
Gas Barbecues Assembly and Operating Instructions for Outback® Trooper/Hunter/Ranger Stainless Steel Gas Barbecues EN (Europe) Photographs are not to scale. Specifications subject to change 0359 without prior notice. • For outdoor use only. Not for commercial use. • Read instructions before using the appliance. Failure to follow instructions could result in death, serious bodily injury, and/or property loss. -
Page 2: Parts List
A. Parts List Specifications subject to change without prior notice. For more details on hardware, please see ‘Hardware Reference Diagram’. Outback® Trooper Outback® Hunter Outback® Ranger CODE PART Stainless Steel Stainless Steel Stainless Steel Hood (Pre-Assembled to Body) Hood Hinge Pin... -
Page 3: Parts Diagrams
B. Parts Diagrams Quantities vary according to model purchased. Specifications subject to change without prior notice. For more details on hardware, please see ‘Hardware Reference Diagram’. - Page 4 C. Hardware Reference Diagram Specifications subject to change without prior notice. D2, D3, D4...
-
Page 5: Tools Needed For Assembly
D. Assembly TOOLS NEEDED FOR ASSEMBLY: Medium size flat blade or Philips/crosspoint screwdriver, adjustable spanner or metric spanner set. (Photo depicts trolley from the reverse side) Attach the short (C2) and long legs (C3) to the trolley base (C5) using the trolley bolts (D1). - Page 6 Turn the trolley over so that it stands on its side shelves. Slide the axle (C6) through the corresponding holes in the short legs (C2). Place a washer (C8) on each end of the axle. Slide the wheels (C7) over each end of the axle. Secure the wheels into place with the locknuts (C9).
- Page 7 Lay the assembled trolley on its back. Lay the body (B6) on its back and slide into position between the trolley legs. Warning: Care must be taken to ensure hood does not fall open unexpectedly. When positioning the body of the barbecue, ensure the control panel is on the same side as the legs with Velcro fastenings.
- Page 8 Stand the barbecue upright. Replace the drip tray (B10) by sliding it underneath the barbecue body. Remove the plastic wrap from the lava rock Lay the cooking grill (B1) into the left basket(s) (B3) and lay them carefully into side of the barbecue body. the body ensuring that they lie level within the body.
- Page 9 Lay the cooking griddle (B2) into the right side of the barbecue body, Lay the warming rack (A5) into the barbecue Hood. 2 burner model configuration: Left/Right — Cooking Grills, Rock Baskets 3 burner model configuration: Left — Cooking Grills, Rock Baskets; Right— Cooking Griddle 4 burner model configuration: Left half—Cooking Grill, Rock Basket;...
- Page 10 (Rear view of the barbecue trolley.) Attach the screen (C4) to the front legs as shown. Leak Test Diagram ASSEMBLY IS NOW COMPLETE. PROCEED TO THE NEXT PAGE FOR INSTRUCTIONS ON OPERATION AND MAINTENANCE.
-
Page 11: Installation
E. Important Information F. Gas and Regulator Please read these instructions carefully This barbecue can use either propane or before assembly and use. butane LPG bottled gas. Propane bottles, will supply gas all year round, even on cold Retain these instructions future winter days. -
Page 12: Operation
of the hose should touch any hot barbecue This barbecue is not designed to be used parts. Always inspect the hose for cuts, with more than 50% of the cooking area cracks, or excessive wear before use. If the as a solid plate. Full coverage of plates hose is damaged, it must be replaced with will cause excessive build-up of heat and hose suitable for use with LPG and meet the... - Page 13 the control panel and place near leftmost When roasting, turn the burner directly under burner porthole. the food to the OFF position. Turn all other • Push and turn the leftmost control knob burners to a LOW to MEDIUM position and close the hood.
-
Page 14: Care And Maintenance
I. CARE AND MAINTENANCE residue. Replacement lava rock is available Regularly clean your barbecue between uses from your local Outback® stockist. and especially after extended periods of storage. Ensure the barbecue and its I4. -
Page 15: Technical Specifications
It is not necessary to Approval Input Size Pressure remove all the grease from the body. If you Butane/ Outback® need to clean fully, use hot soapy water and 28mbar Trooper 0359 7.87kW Propane/ a cloth, or nylon-bristled brush only. Use a... -
Page 16: Troubleshooting
K. Troubleshooting Problem Possible Cause Solution Burners will not light using LP gas bottle is empty Replace with full bottle the ignition system Faulty regulator Have regulator checked or replaced Obstructions in burners Clean burners Obstructions in gas jets or gas hose Clean jets and gas hose Electrode wire is loose or disconnected Reconnect wire...
