Assembly and Operating Instructions for Outback®
Trooper Plus, Hunter Plus Gas Barbecues
Photographs are not to scale.
Specifications subject to change
without prior notice.
•
•
•
•
•
•
WARNING
•
•
•
FOR YOUR SAFETY
If you smell gas:
1.
Shut off gas to the appliance.
2.
Extinguish any open flame.
3.
Open barbecue lid or hood.
4.
If odour continues, discontinue use and
contact your local dealer.
Gas Barbecues
For outdoor use only. Not for commercial use.
Read instructions before using the appliance. Failure to follow instructions
could result in death, serious bodily injury, and/or property loss.
Warning: accessible parts may be very hot. Keep young children away.
Do not move the appliance during use.
Turn off the gas supply at the gas bottle after use.
Any modification of the appliance, misuse, or failure to follow the instructions
may be dangerous and will invalidate your warranty. This does not affect your
statutory rights.
Retain these instructions for future reference.
Leak test annually, and whenever the gas bottle is removed or replaced.
For Flare-up control please refer to the 'OPERATION' section of this manual.
1.
2.
FOR YOUR SAFETY
Do not store or use petrol or other flammable
vapours or liquids in the vicinity of this or
any other appliance.
A gas bottle not connected for use shall not
be stored in the vicinity of this or any other
appliance.
EN (Europe)
0359
Advertisement
Related Manuals for Outback Trooper Plus
Summary of Contents for Outback Trooper Plus
- Page 1 Gas Barbecues Assembly and Operating Instructions for Outback® Trooper Plus, Hunter Plus Gas Barbecues EN (Europe) Photographs are not to scale. Specifications subject to change 0359 without prior notice. • For outdoor use only. Not for commercial use. • Read instructions before using the appliance. Failure to follow instructions could result in death, serious bodily injury, and/or property loss.
- Page 2 Quantities vary according to model purchased. Specifications subject to change without prior notice. For more details on hardware, please see ‘Hardware Reference Diagram’. Outback® Outback® CODE PART Trooper Plus Hunter Plus Hood Handle L/H Hood Handle Bracket R/H Hood Handle Bracket HOOD...
- Page 3 B. Parts Diagrams Quantities vary according to model purchased. Specifications subject to change without prior notice. For more details on hardware, please see hardware pack page.
- Page 4 C. Hardware Reference Diagram Specifications subject to change without prior notice.
- Page 5 D. Assembly TOOLS NEEDED FOR ASSEMBLY: Medium size flat blade or Phillips/crosspoint screwdriver, adjustable spanner or metric spanner set. Whilst every care is taken in the manufacture of this product, care must be taken during assembly in case sharp edges are present. (Photo depicts trolley from the reverse side) Attach the legs (C2,C3,C4,C5) to the trolley base (C11) using the trolley bolts (D1).
- Page 6 Attach the side shelves (C1) to the front/rear left legs (C2,C3) and front/rear right legs (C4,C5) using the trolley bolts (D1). Remove all cast iron cooking components, Flame Tamer, drip tray, and any internal packaging from the barbecue body. Note: Loosen off the bolts and move the brackets down to their lowest position. Retighten the bolts.
- Page 7 Lay the assembled trolley on its side. Lay the body (B1) on its back and slide into position between the trolley legs. Warning: Care must be taken to ensure hood does not fall open unexpectedly. When positioning the body of the barbecue, ensure the control panel is on the same side as the legs with Velcro fastenings.
- Page 8 Replace the drip tray (B9) by sliding it underneath the barbecue body. Lay the flame tamer (B5) into the body ensuring it lie level within the body. Lay the grills (B6, B7) and griddle (B8) into place. 2 burner model configuration: Left — Large Cooking Grill, Right — Small Cooking Grill, 3 burner model configuration: Left —...
- Page 9 (Rear view of the barbecue trolley.) Attach the warming rack (B11) to the Attach the screen (C6) to the front left/right hood as shown. legs as shown. Connect the gas hose to the BBQ. Ensure the mating faces of the connection are clean and not damaged.
-
Page 10: Hood Handle
E. Important Information F. Gas and Regulator Please read these instructions carefully This barbecue can use either propane or before assembly and use. butane LPG bottled gas. Propane bottles, will supply gas all year round, even on cold Retain these instructions future winter days. -
Page 11: Burner 2
of the hose should touch any hot barbecue This barbecue is not designed to be used parts. Always inspect the hose for cuts, with more than 50% of the cooking area cracks, or excessive wear before use. If the as a solid plate. Full coverage of plates hose is damaged, it must be replaced with will cause excessive build-up of heat and hose suitable for use with LPG and meet the... -
Page 12: Knob
match-lighting hole on the underside of H7. Roasting Hood Cooking the control panel and place near Barbecues equipped with a roasting hood leftmost burner porthole. give the option of cooking with hood closed • to form an ‘oven’ for roasting food, such as Push and turn the leftmost control knob joints of meat, whole chickens, etc. -
Page 13: Drip Tray
Outback® stockist. sparingly and try to avoid very cheap cuts of meat or meat products as these tend to have a I1. -
Page 14: Side Shelf
Pressure manifold in water. Check burner operation after carefully refitting into body. Butane/ 28mbar I6. Barbecue Hood Propane/ Outback® 0359 Use a non-abrasive cloth or pad and clean 37mbar Trooper 7.87kW 359AS128 with hot, soapy water. Do not use scouring... - Page 15 K. Troubleshooting Problem Possible Cause Solution Burners will not light using LP gas bottle is empty Replace with full bottle the ignition system Faulty regulator Have regulator checked or replaced Obstructions in burners Clean burners Obstructions in gas jets or gas hose Clean jets and gas hose Electrode wire is loose or disconnected Reconnect wire...
