Assembly and Operating Instructions for
Photographs are not to scale.
Specifications subject to change
without prior notice.
WARNING
FOR YOUR SAFETY
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flame.
3. Open barbecue lid or hood.
4. If odour continues, discontinue use and
contact your local dealer.
Outback® Tungsten Gas Barbecue
THG2710
For outdoor use only. Not for commercial use.
Read instructions before using the appliance. Failure to follow instructions could
result in death, serious bodily injury, and/or property loss.
Warning: accessible parts may be very hot. Keep young children and pets away.
Do not move the appliance during use.
Turn off the gas supply at the gas bottle after use.
Any modification of the appliance, misuse, or failure to follow the instructions may
be dangerous and will invalidate your warranty. This does not affect your statutory
rights.
Retain these instructions for future reference.
Leak test annually, and whenever the gas bottle is removed or replaced. Check that
the hose connections are tight and leak test each time you reconnect the gas bottle.
For Flare-up control please refer to the 'OPERATION' section of this manual.
FOR YOUR SAFETY
1. Do not store or use petrol or other flammable
vapours or liquids in the vicinity of this or any
other appliance.
2. A gas bottle not connected for use must not be
stored in the vicinity of this or any other
appliance.
EN (Europe)
0359

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the THG2710 and is the answer not in the manual?

Questions and answers

Related Manuals for Outback THG2710

Summary of Contents for Outback THG2710

  • Page 1 Assembly and Operating Instructions for Outback® Tungsten Gas Barbecue EN (Europe) THG2710 Photographs are not to scale. Specifications subject to change 0359 without prior notice. For outdoor use only. Not for commercial use. Read instructions before using the appliance. Failure to follow instructions could result in death, serious bodily injury, and/or property loss.

  • Page 2: Parts List

    1. Parts List Quantity varies according to model purchased. Specifications subject to change without prior notice. For more details on hardware, please see the corresponding ‘Hardware Reference Diagram’. Outback® CODE PART Tungsten Hood (Pre-Assembled to Body)  Hood Handle ...

  • Page 3: Parts Diagram

    2. Parts Diagram Quantity varies according to model purchased. Specifications subject to change without prior notice. For more details on hardware, please see the corresponding ‘Hardware Reference Diagram’.
  • Page 4 3. Hardware Reference Diagram Specifications subject to change without prior notice. D2,D3,D4 D5,D6...
  • Page 5 4. Assembly IMPORTANT! TOOLS NEEDED FOR ASSEMBLY: Medium size flat blade or Phillips/Crosspoint screwdriver, adjustable spanner or metric spanner set. The assembly of this barbecue requires 2 people. The inlet connection of the gas rail assembly on the barbecue body is lower than the body. You must never allow the pipe to rest on the ground during assembly as serious damage could result.
  • Page 6 Attach the Bottom Slat Assembly (C12) to the Base Tray (C13) using M6x15 Bolts (D5). Attach the leg assembly to the Base Tray (C13) using M6x15 Bolts (D5).
  • Page 7 Threaded Insert Attach the Left Front Leg (C8) and Left Rear Leg (C9) to the Gas Bottle Holder (C14). Note: Threaded inserts must be facing in the direction shown! Align the Gas Bottle Holder (C14) with the Bottom Slat Assembly (C12).
  • Page 8 Attach the Gas Bottle Holder (C14) to the Bottom Slat Assembly (C12) using M6x15 Bolts (D5) and Ø6 Washers (D6). Unscrew the Locknuts (D9) from both ends of the Axle (C18). Insert the axle through the clamping brackets into the Gas Bottle Holder (C14) and tighten the clamp bolts.
  • Page 9 Slide the Wheels (C17) over each end of the axle. Secure the wheels into place with the locknuts. Carefully turn the completed trolley over, right side up. Place the wheel Hubcaps (C16) onto the outsides of the wheels.
  • Page 10 Remove all cooking components, flame tamer / lava rock, and any internal packaging from the Barbecue Body (B1). Carefully turn the barbecue body upside-down. CAUTION! Care must be taken to ensure the hood or lid does not fall open unexpectedly or becomes damaged when it is set on the ground. Attach the Right Side Shelf (C6) to the barbecue body using M6x15 Bolts (D5).
  • Page 11 Attach the Front Left Endcap (C3) to the barbecue body using M6x15 Bolts (D5). Attach the Rear Left Endcap (C4) to the barbecue body using M6x15 Bolts (D5).
  • Page 12 Carefully turn the barbecue body over right-side-up. CAUTION! Care must be taken to ensure the hood or lid does not fall open unexpectedly or becomes damaged when it is set on the ground. Carefully place the barbecue body onto the tops of the legs. The tops of the legs should slot into the endcaps.
  • Page 13 Secure the Legs (C8, C9, C10, C11) to the Endcaps (C3, C4) and the Right Side Shelf (C6) using M6x35 Bolts (D7). Attach the Side Shelf Shield (C2) to the endcaps using the M4x15 Bolts (D1).
  • Page 14 Attach the Side Shelf Hooks (C21) to the Left Side Shelf (C1) using 1/4-20UNCx12 Bolts (D8), then hook the side shelf to the endcaps. Lay the Utensil Trays (C5) into their positions on either side of the barbecue body.
  • Page 15 Slide the loops of the Gas Bottle Strap (C20) onto the Retaining Rod (C19). Secure the rod to the trolley legs using M6x15 Bolts (D5). Attach Drip Tray Right Bracket (B10) to barbecue body using M5x15 Bolts (D2), Ø5 Washers (D3) and M5 Nuts (D4) as shown.
  • Page 16 Carefully lay the Flame Tamer / Lava Rock (B6) into the barbecue body ensuring it lies level within the body. Lay the Grill (B7) and Griddle (B8) into place. Configuration: Left — Cooking Grill, Right — Cooking Griddle NOTE: Ensure that the lava rock lies directly underneath the grills. No lava rock is required when using the flame tamer.

  • Page 17: Leak Testing

    Turn off the gas supply at the gas bottle Retighten all joints Repeat test If bubbles form again do not use the barbecue and contact your local Outback distribu- tor for assistance. Always wipe the mixed solution (½ water and ½ liquid detergent / soap) from all joints...

  • Page 18: Gas, Regulator And Hose

    5. Important Information leak test. This is the only safe and sure way to detect any gas leaking from joints and connections of the barbecue after assembly. Please read these instructions carefully before assembly and use of your barbecue.  Leak test annually, and whenever the gas bottle is removed or replaced.

  • Page 19: Installation

    DANGEROUS AND WILL INVALIDATE ANY Full coverage will cause excessive build-up WARRANTY. Please consult your local gas of heat and damage the barbecue. This is dealer for the most suitable gas bottles and not covered by warranty. regulators. 8.2. Preparation Before Cooking To prevent foods from sticking to the cooking surface, please use a long handled brush to 7.
  • Page 20 hood or lid closed. done with the burners on low. Ensure all knobs are in the off position. For best results, place the food you wish to Open the gas control valve on the gas bake or roast on a metal baking tray and set it bottle or regulator.

  • Page 21: Care And Maintenance

    Heavy-duty Outback® foods or cheap meat products are being barbecue covers and other accessories are cooked. Failure to do this may result in a fat fire, available from your local Outback® stockist. which may cause injury and could seriously...
  • Page 22 Replacement lava rock is a heat resistant paint. available from your local Outback® stockist. 9.5. Drip Tray A chrome cleaner may be used on chrome parts if required. To prevent rusting, wipe After every use, empty and clean the drip tray chrome plated warming racks etc.

  • Page 23: Technical Specifications

    30 mbar LPG mixture 9.9. Fixings Gas Consumption: All screws and bolts, etc. should be checked Outback® Tungsten: 570g/hr and tightened on a regular basis. Countries of Use: BE, CH, CY, CZ, ES, FR, GB, GR, IE, IT, LT, LU, LV, PT, 3+ (28-30/37) 9.10.

  • Page 24: Troubleshooting

    11. Troubleshooting Problem Possible Cause Solution Burner will not light using LP gas bottle is empty Replace with full bottle the ignition system Faulty regulator Have regulator checked or replaced Obstructions in burner Clean burner Obstructions in gas jets or gas Clean jets and gas hose hose Electrode or ignition button wire is...
