Assembly and Operating Instructions for Outback® Mayfair/Tungsten,
Outback® Spirit/Titanium, and Outback® Performance/Platinum Hooded Gas Barbecues
Photographs are not to scale.
Specifications subj ect to change
without prior notice.
•
•
•
•
•
•
•
WARNING
•
FOR YOUR SAFETY
If you smell gas:
1.
Shut off gas to the appliance.
2.
Extinguish any open flame.
3.
Open barbecue lid or hood.
4.
If odour continues, discontinue use and
contact your local dealer.
Elite Series Barbecues
For outdoor use only.
Read instructions before using the appliance. Failure to follow instructions
could result in death, serious bodily injury, and/or property loss.
Warning: accessible parts may be very hot. Keep young children away.
Do not move the appliance during use.
Turn off the gas supply at the gas bottle after use.
Any modification of the appliance, misuse, or failure to follow the instructions
may be dangerous and will invalidate your warranty. This does not affect your
statutory rights.
Retain these instructions for future reference.
Leak test your barbecue annually. Check the hose connections are tight and leak
test each time you reconnect the gas bottle.
FOR YOUR SAFETY
1.
Do not store or use petrol or other flammable
vapours or liquids in the vicinity of this or any
other appliance.
2.
A gas bottle not connected for use shall not be
stored in the vicinity of this or any other
appliance.
0359
Advertisement
Table of Contents
Related Manuals for Outback Mayfair
Summary of Contents for Outback Mayfair
-
Page 1: For Your Safety
Elite Series Barbecues Assembly and Operating Instructions for Outback® Mayfair/Tungsten, Outback® Spirit/Titanium, and Outback® Performance/Platinum Hooded Gas Barbecues Photographs are not to scale. Specifications subj ect to change 0359 without prior notice. • For outdoor use only. • Read instructions before using the appliance. Failure to follow instructions could result in death, serious bodily injury, and/or property loss. -
Page 2: Table Of Contents
Parts List Quantities v ary according to model purchased. Specifications subject to change without prior notice. For more details on hardware, please see ‘Hardware Reference Diagram’. Mayfair/ Spirit/ Performance/ CODE PART Tungsten Titanium Platinum Hood H andl e L/H Hood Handle Brac ket... -
Page 3: Parts Diagrams
Parts Diagrams Quantities v ary according to model purchased. Specifications subject to change without prior notice. For more details on hardware, please see ‘Hardware Reference Diagram.’... - Page 4 Hardware Reference Diagram Specif ications subject to change without prior notice. D2 (screw) D3(washer)
- Page 5 Assembly IMPORTANT! • Tools Required: Medium size f lat blade or Phillips/Crosspoint screwdriv er, adjustable spanner or metric spanner set • The assembly of this barbecue requires 2 people. • Caref ully unpack the trolley box and remov e all internal packaging bef ore commencing assembly. •...
- Page 6 Attach the Bottom Slat Assembly (C12) to the Base Tray (C13) using the Screws (D2). Attach the leg assembly to the Base Tray (C13) using the Screws (D2).
- Page 7 Threaded Insert Attach the Front Left Leg (C8) and Rear Left Leg (C9) to the Gas Bottle Holder (C14). Align the Gas Bottle Holder (C14) with the Slat Assembly (C12).
- Page 8 Attach the Gas Bottle Holder (C14) to the Bottom Slat Assembly (C12) using the Screws (D2) and Washers (D3). Insert the axle (C19) through the clamping brackets on the gas bottle holder (C14) and tighten the clamp screws. Take care not to over tighten these screws which will damage the plastic Gas Bottle Holder.
- Page 9 Place the Wheels (C17) onto the Axle (C19) and secure with Locknuts (C18). Caref ully turn the completed trolley over, right side up.
-
Page 10: Barbec Ue Body
CAUTION! Care must be taken to ensure hood does not fall open unexpectedly or that the hood surface is damaged when set on the ground. Caref ully turn the Barbecue Body (B1) upside down and remove the Drip Tray (B6). Attach the R/H Side Shelf (C6) to the Barbecue Body (B1) using the Screws (D2). - Page 11 Attach the Rear Left Endcap (C4) to the Body (B1) using the Screws (D2). CAUTION! Care must be taken to ensure hood does not fall open unexpectedly. Caref ully turn the Barbecue Body (B1) over right-side-up.
- Page 12 Caref ully lay the Barbecue Body (B1) onto the tops of the legs. The tops of the legs should slot into the endcaps. When done correctly, the barbecue should be able to stand on its own weight. WARNING: DO NOT RELEASE THE BARBECUE BODY WHILE THE BARBECUE HAS NOT BEEN PROPERLY SEATED.
- Page 13 Attach the Side Shelf Shield (C2) to the endcaps using the Countersunk Screws (D1). Hook the L/H Side Shelf (C1) to the endcaps.
- Page 14 Lay the Utensil Tray s (C5) into their positions on either side of the barbecue body. Place the Wheel Hubcaps (C16) onto the sides of the Wheels (C17)
- Page 15 Slide the loops of the Gas Bottle Strap (21) onto the Retaining Rod (C20). Secure the Rod (C20) to the trolley legs using the Screws (D2). Ensure the strap is threaded through the buckle correctly. It must hold the gas bottle firmly in place onto the barbecue.
-
Page 16: Grill
Place the Foil Liner (B8) into the Drip Pan (B7) and slide into place. Remov e the plastic wrap f rom the Lava Rock Baskets (B9) and lay them caref ully into the body ensuring that they lie lev el within the body. Lay the Grills (B11) and Griddle (B12) into place. 2 Burner Configuration: Left half - Grill, Rock Basket;... -
Page 17: Hose
Connect the gas hose (B13) to the BBQ. Ensure the mating faces of the connection are clean and not damaged. Do not use any sealing tape, paste, or liquid on the joint. The nut must be tightened with the use of a spanner. Do not use f orce which may damage the assembly. Assembly is now complete. - Page 18 ESSENTIAL INFORMATION Please read instructions before using your barbecue. BEFORE YOU USE YOUR BARBECUE (also see installation) • Perf orm a leak test. This is the only safe and sure way to detect any gas leaking from joints and connections of the barbecue after assembly. Follow the leak test instructions on page 20. Check that the gas hose is f ree of any tension, twisting, cuts, or cracks.
-
Page 19: Warmi Ng Rack
Outback® stockists. • Ev en when y our barbecue is cov ered for its protection, it must be inspected on a regular basis as damp or condensation can form which may result in damage to the barbecue. It may be necessary to dry the barbecue and the inside of the cov er. - Page 20 Repeat test • If bubbles form again do not use the barbecue and contact y our local Outback dealer f or assistance or call Outback customer services on (01622) 671771. Customer services are av ailable during normal office hours, Monday to Friday, 9am to 5pm.
- Page 21 Do not leav e the BBQ uncovered and exposed to the elements when not in use. Heavy duty covers are av ailable as an accessory from your Outback ® stockist. Even when y our barbecue is cov ered f or its protection, it must be inspected on a regular basis as damp or condensation can f orm which may result in damage to the barbecue.
- Page 22 that is found that does not come into contact with the food should be treated with a rust inhibitor and painted with barbecue paint or a heat resistant paint. Wooden parts may also need to be cleaned and treated. Chrome plated warming racks etc. should be coated with cooking oil. •...
-
Page 23: Utensil Tray
Cleaning Material Where used Cleaning Method Recommended Porcelain Grills Enamel is a thin, glass based coating fused onto metal and enamel Griddles as such needs to be treated with care. Cooking oil, together Hood with f at from f ood being cooked can turn to carbon as a result of heating and result in black f lakes coming away from the cooking surf aces. -
Page 24: Troubleshooting
Troubleshooting Problem Possible Cause Solution Burners will not light LP gas bottle is empty Replace with full gas bottle using the ignition system Faulty regulator Have regulator checked or replace Obstructions in burners Clean burners Obstructions in gas jets Clean jets and gas hose or gas hose Electrode wire is loose or Reconnect wire... - Page 25 This number may be required when ordering spare parts or accessories. A part reference number may also be required where applicable. In the unlikely event that you experience problems with this barbeque, please contact: Customer Service Outback UK Unit 2 Farleigh Hill Tovil Maidstone...
