Programming

Access the Main menu

The Main menu provides access to the camera configuration options. The on-
screen display (OSD) is only available in English.
Program the camera by attaching a standard video monitor to the system.
Figure 5: The Main menu
To access the menus:
1. Press the OSD control pad to access the Main menu and its submenus.
2. Push the pad up, down, left and right to move between menu options.
3. Press the OSD control pad (Enter) to select an option.
4. When in a sub menu, select
5. To exit the Main menu, move the cursor to
and press Enter. All changes are saved.

General menu

Select the General
Figure 6: The General menu
Table 2: General menu
Parameter
ID display
Mirror
UltraView UVD-6120VE-2 Digital WDR Dome Camera User Manual
Return
option from the Main menu to enter the General menu.
Description
Displays the camera ID on screen. Default option is Off.
Flips the camera image so that it is correctly orientated for viewing.
to return to the previous menu.
Exit at the bottom of the screen
7
