Interlogix UltraView XP4 series Specifications

UltraView XP4 Series /
™
WDR Box
Cameras
High-res, vandal-resistant,
varifocal lens cameras
Overview
The UltraView XP4 WDR Box camera provides high-quality
™
surveillance images in a variety of discreet commercial
applications. Featuring superior wide dynamic range and low-light
performance in an all-in-one package, the UltraView XP4 is well
suited for the most demanding environments.
The UltraView XP4 comes standard with true day/night
functionality with removable IR cut filter, BNC, and UTP
connections. Utilizing a Pixim Seawolf chipset with customized
Interlogix firmware, each pixel is individually optimized to show
details in shadows and highlights. The UltraView XP4 also offers
a recording device with 690 HTVL of effective total resolution and
delivers usable images in the most challenging high-contrast and
mixed-lighting conditions.
Video Surveillance

Standard featureS

• WDR up to 120 dB
• Exceptional performance in almost any lighting conditions
• True day/night (removable IR cut filter)
• Standard BNC and UTP connections
• 12 VDC/24 VAC
applicatiOn
UltraView Box cameras are notable for their ability to work in just
about any environment. Because these cameras perform in extreme
high- and low-light situations, they are pre-configured out of the
box to fit most security applications. UltraView XP4 Box cameras
are ideal for exterior installations (when an environmental housing is
used), including shipping ports and banking institutions as well as
parking lots, and are well-suited for indoor applications including retail
environments and healthcare facilities.
Powered by
SEAWOLF
interlogix.com
