Table 5: D/N mode menu
Menu item Description
Auto When set to Auto Day/Night mode, the camera produces high-quality color
video during the day or when light levels are high. It then switches to
monochrome and removes the infrared filter to improve IR sensitivity at
night or when light levels are low. Set following parameters:
Day→Night: Set the threshold level on how dark it should be before
switching from Day to Night mode. Lower (Higher) value makes the
camera switched from Day to Night at lower (higher) illumination
Night→Day: Set the threshold level on how light it should be before
switching from Night to Day mode.
Delay seconds: This is the time in seconds before Day↔Night switches.
A long delay response would be used, for example, to avoid switching
from Night to Day mode when car headlights pass in front of the camera.
CAUTION: If there is a minimal difference between the Day→Night and
Night→Day values, then camera may switch between Day and Night
mode repeatedly.
Day Manually select Day mode only. The camera can only be in Day mode.
Night Manually select Night mode only. The camera can only be in Night mode.
Ext Externally triggered D/N.
Return Press
Exit & Save Exits the menu and returns to live mode. Saves changes made.

Motion alarm menu

A motion detection alarm is an alarm that is triggered when the camera detects a
motion. You can define up to four areas on screen where the motion can be
detected as well as the level of sensitivity to motion.
Select the Motion option from the Main menu to enter the Motion menu.
Figure 9: Motion menus
10
Enter to return to the previous menu.
