UVD-XP4DNR(-P)
Camera Quick Start
Guide

P/N 1079205B-EN • REV 1.0 • ISS 15JUN12

Advertisement

Table of Contents
loading

Related Manuals for Interlogix UVD-XP4DNR-P

Summary of Contents for Interlogix UVD-XP4DNR-P

  • Page 1 UVD-XP4DNR(-P) Camera Quick Start Guide   P/N 1079205B-EN • REV 1.0 • ISS 15JUN12...

  • Page 3: Osd Control Pad

    Description The UVD-XP4DNR(-P) camera consists of the following parts: • The camera assembly • Monitor output cable • Mounting screws, wall anchors, and hex key Figure 1: The camera assembly and monitor output cable Lens body Camera body Bubble Monitor output BNC Video monitor output Monitor output RCA OSD control pad...

  • Page 4: Installation

    OSD control pad Table 1 lists the OSD control pad functions and describes their use. Table 1: OSD control pad functions Pad directions Description Moves the cursor upward to select an item. Left Moves the cursor left to select or adjust the parameters of the selected item.

  • Page 5: Camera Installation

    White cable. Video out. Black cable. Video ground. Note: For AC24V or DC12V, Black or Red may be used for ground. Camera installation To mount the camera, attach the camera to the mounting surface using the appropriate fasteners. Angle adjustment To adjust the horizontal angle of the platform up to 180 degrees, turn the platform (1).

  • Page 6: Connect The Monitor

    1. Loosen the zoom ring thumbscrew. 2. Turn the zoom ring to set the desired zoom. 3. Tighten the zoom ring thumbscrew. 4. Loosen the focus ring thumbscrew. 5. Turn the focus ring to set the desired focus. 6. Tighten the focus ring thumbscrew. Connect the monitor Program the cameras by attaching a standard video monitor to the system.
  • Page 7 Table 2: Main menu options Menu option Function Presets Configures the preset for the lighting condition. Setup Configures camera ID, motion detection, and wide dynamic range options. Viewing Configures flip and resolution. Exposure Configures automatic gain control (AGC), AE preferences, shutter limit, frame report, and B/W control.
  • Page 8 Table 2: Main menu options Menu option Function Presets Configures the preset for the lighting condition. Setup Configures camera ID, motion detection, and wide dynamic range options. Viewing Configures flip and resolution. Exposure Configures automatic gain control (AGC), AE preferences, shutter limit, frame report, and B/W control.

  • Page 9: Menu Map

    Menu Map Quick Start Guide 7 EN...
