Usb Copy; Typical Setup Procedure - Thecus N2800 User Manual

Link Aggregation
System Fan
CPU Fan
2009/05/22 12:00
RAID
The Thecus IP storage will rotate these messages every one-two seconds on the
OLED display.

USB Copy

The USB Copy function enables you to copy files stored on USB devices such as USB
disks and digital cameras to the Thecus IP storage by press USB copy button. To
use USB copy, follow the steps below:
N2800:
1. Plug your USB device into an available USB port on the Rear Panel.
2. Press the "USB Copy Button".
3. The N2800 will start copying USB disks connected to the rear USB port. The
LCD will display the USB copy progress and result.
N4800 Series:
1. Plug your USB device into an available USB port on the Front end.
2. In Display Mode, press the Down Button (▼).
3. The OLED will display "USB Copy?"
4. Press Enter (
connected to the front USB port.
5. All of data will be copied into system folder named "USB copy".

Typical Setup Procedure

From the Web Administration Interface, you can begin to setup your Thecus IP
storage for use on your network. Setting up the Thecus IP storage typically follows
the five steps outlined below.
For more on how to use the Web Administration Interface, see
Chapter 4: Web Administration
Step 1: Network Setup
From the Web Administration Interface, you can configure the network settings of
the Thecus IP storage for your network. You can access the Network menu from
the menu bar.
For details on how to configure your network settings, refer to
Chapter 4: System Network
Step 2: RAID Creation
Current Link Aggregation status
Current system fan status.
Current CPU fan status
Current system time.
Current RAID status.

) and the N4800 Series will start copying USB disks
Interface.
.
19
